Alchemy Atlas — Red Etap AXS Road 2019
2019 Road
Estimate price |
10,499$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset RED eTAP -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
52cm
160cm - 167cm
54cm
164cm - 174cm
56cm
171cm - 182cm
58cm
179cm - 189cm
61cm
187cm - 193cm
Parts list
Components
Main components, grouped by system.
Bike components
Drivetrain
Rear Derailleur
SRAM Red Etap AXS 12 Speed
Front Derailleur
SRAM Red Etap AXS 12 Speed
Shift Levers
SRAM Red Etap AXS 12 Speed
Cassette
SRAM Red 12 Speed 10-33
Crank
SRAM Red AXS 46/33 172.5
Bottom Bracket
SRAM DUB PF86 41mm
Chain
SRAM Red 12 Speed
Wheels
Rims
ENVE 3.4 SES Disc
Tires
Continental Grand Prix 5000 S II Tire 700 x 28 Black
Brakes
Brakes
SRAM Red AXS eTap Disc
Disk Rotors
SRAM CenterLine 140mm
Cockpit
Stem
ENVE Road
Handlebar
ENVE Road Compact
Headset
Cane Creek 40-Series IS42/IS52
Seat
Saddle
Fizik Antares R7
Seatpost
ENVE Road
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 52cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.43 mm | 1.46 mm | 1.49 mm | 1.49 mm |
| Bottom Bracket Height | 266 mm | 266 mm | 266 mm | 266 mm | 266 mm |
| Front Center | 580 mm | 580 mm | 590 mm | 600 mm | 620 mm |
| Rake | 32 mm | 35 mm | 38 mm | 39 mm | 36 mm |
| Trail | 60.8 mm | 58.6 mm | 57.4 mm | 55.5 mm | 53.7 mm |
| Stack | 527 mm | 552 mm | 574 mm | 594 mm | 614 mm |
| Reach | 372 mm | 385 mm | 392 mm | 398 mm | 413 mm |
| Top Tube Length | 524 mm | 545 mm | 562 mm | 577 mm | 603 mm |
| Seat Tube Angle | 74 ° | 73.8 ° | 73.5 ° | 73.2 ° | 72.8 ° |
| Seat Tube Length | 470 mm | 520 mm | 540 mm | 560 mm | 575 mm |
| Head Tube Angle | 71.5 ° | 73 ° | 73.2 ° | 73.5 ° | 73.8 ° |
| Head Tube Length | 130 mm | 150 mm | 170 mm | 190 mm | 210 mm |
| Chainstay Length | 417 mm | 417 mm | 417 mm | 417 mm | 417 mm |
| Wheelbase | 967 mm | 977 mm | 992 mm | 1002 mm | 1017 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 160 cm | 164 cm | 171 cm | 179 cm | 187 cm |
| Rider Max Height | 167 cm | 174 cm | 182 cm | 189 cm | 193 cm |
Model Overview
Atlas — Red Etap AXS Road is part of the Alchemy Atlas model. 59 bikes variations carry this model name so far. You can easily view all of the Alchemy Atlas bikes models from 2019, here.
Model range prices
The most economical model, the Alchemy Atlas — Ultegra Mechanical Disc 2019 has a starting price of 6499$. Alchemy Atlas — Dura Ace Di2 Disc ENVE 2019 on the other hand is the most expensive at 10499$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Race bikes average price
If you want an acceptable Race bike you should know that the average price is 3350$. However, even though the average price of a Race bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When Alchemy released this model in 2019, its price was 10499$. In conclusion, this bike price is 213.4% more expensive than the price of the average Race bike.
Atlas — Red Etap AXS Road components
Fork material
Atlas — Red Etap AXS Road has a carbon fork, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
As for the wheels, Alchemy Atlas — Red Etap AXS Road 2019, has a 700c carbon model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Alchemy Atlas — Red Etap AXS Road is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
Alchemy Atlas — Red Etap AXS Road bike has 5 sizes, in the range of 160 cm – 193 cm (5.25 ft – 6.33 ft). In conclusion, finding one for you shouldn’t be a problem.
