Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset X01 Eagle AXS, Force eTap -
Suspension Rigid -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Drivetrain
Rear Derailleur
SRAM X01 Eagle AXS
Shift Levers
SRAM Force AXS
Cassette
SRAM XG-1295 Eagle 10-50
Crank
SRAM Force 1 D2 Crankset 40t
Bottom Bracket
SRAM DUB
Chain
SRAM X01 Eagle
Wheels
Rims
Industry Nine UL250 Carbon CX 700c
Tires
WTB Resolute 700x42 TCS 120tpi SG2
Brakes
Brakes
SRAM Force D2 HRD
Cockpit
Stem
FSA Energy SCR Stem
Handlebar
FSA Adventure Compact
Seat
Saddle
Selle Italia Model X
Seatpost
FSA SL-K Carbon Seatpost
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.46 mm | 1.48 mm | 1.51 mm | 1.52 mm |
| Bottom Bracket Height | 279 mm | 279 mm | 279 mm | 279 mm | 279 mm |
| Front Center | 599 mm | 609 mm | 619 mm | 630 mm | 645 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 77 mm | 65 mm | 66 mm | 72 mm | 72 mm |
| Stack | 535 mm | 561 mm | 577 mm | 599 mm | 617 mm |
| Reach | 378 mm | 384 mm | 389 mm | 398 mm | 407 mm |
| Top Tube Length | 533 mm | 546 mm | 555 mm | 578 mm | 593 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 73.25 ° | 73.25 ° |
| Seat Tube Length | 470 mm | 520 mm | 540 mm | 560 mm | 580 mm |
| Head Tube Angle | 70 ° | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 120 mm | 143 mm | 160 mm | 180 mm | 200 mm |
| Chainstay Length | 422 mm | 422 mm | 422 mm | 422 mm | 422 mm |
| Wheelbase | 1011 mm | 1021 mm | 1031 mm | 1042 mm | 1057 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 752 mm | 782 mm | 802 mm | 822 mm | 842 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
ABLE Force AXS belongs to the Allied Able model. There are 28 bikes that carry this model name. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Allied ABLE SRAM Rival AXS 2023 is the most economical model, with a starting price of 6410$. Allied ABLE SRAM Red AXS 2023 on the other hand costs 10120$, and is the most expensive model.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Gravel bikes
According to our calculations, the average cost of a Gravel bike that is reliable is 2462$. However, even if your budget is less than the average, you might still be able to get a top-quality Gravel bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 8335$. Comparing this to the average Gravel bike price, we see that the price is 238.55% more expensive.
ABLE Force AXS components
Fork material
When it comes to the fork, this bike has a carbon one, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
When leaving the production line, the ABLE Force AXS model has 700c carbon wheels. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The ABLE Force AXS has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
This bike is available in 5 sizes. They vary from 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, it won’t be difficult to find the right one for you.
