Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset GX Eagle AXS, Rival AXS -
Suspension Rigid -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Drivetrain
Rear Derailleur
SRAM GX Eagle AXS
Shift Levers
SRAM Rival ETap AXS HRD
Cassette
SRAM Eagle XG-1275 10-50
Crank
SRAM Rival 1 D1 Dub
Bottom Bracket
SRAM DUB Threaded
Chain
SRAM GX Eagle
Wheels
Rims
Industry Nine 1/1 GRCX
Tires
WTB Resolute SG2 700x42
Brakes
Brakes
SRAM Rival AXS Hydraulic w/160mm G3 CL Rotors
Cockpit
Stem
FSA Energy SCR
Handlebar
FSA Adventure Compact Alloy
Seat
Saddle
Selle Italia Model X
Seatpost
FSA Energy Alloy
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.46 mm | 1.48 mm | 1.51 mm | 1.52 mm |
| Bottom Bracket Height | 279 mm | 279 mm | 279 mm | 279 mm | 279 mm |
| Front Center | 599 mm | 609 mm | 619 mm | 630 mm | 645 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 77 mm | 65 mm | 66 mm | 72 mm | 72 mm |
| Stack | 535 mm | 561 mm | 577 mm | 599 mm | 617 mm |
| Reach | 378 mm | 384 mm | 389 mm | 398 mm | 407 mm |
| Top Tube Length | 533 mm | 546 mm | 555 mm | 578 mm | 593 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 73.25 ° | 73.25 ° |
| Seat Tube Length | 470 mm | 520 mm | 540 mm | 560 mm | 580 mm |
| Head Tube Angle | 70 ° | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 120 mm | 143 mm | 160 mm | 180 mm | 200 mm |
| Chainstay Length | 422 mm | 422 mm | 422 mm | 422 mm | 422 mm |
| Wheelbase | 1011 mm | 1021 mm | 1031 mm | 1042 mm | 1057 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 752 mm | 782 mm | 802 mm | 822 mm | 842 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
ABLE Rival AXS is part of the Allied Able model. There are 28 bikes that carry this model name. You can easily view all of the Allied Able bikes models from 2023, here.
Model range prices
The most economical model, the Allied ABLE SRAM Rival AXS 2023 has a starting price of 6410$. Allied ABLE SRAM Red AXS 2023 on the other hand is the most expensive at 10120$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Gravel bikes
According to our calculations, the average cost of a Gravel bike that is reliable is 2462$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Gravel bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
This bike was released in 2023 and its price was 6715$. Comparing this to the average Gravel bike price, we see that the price is 172.75% more expensive.
Overview of components
Fork material
The fork is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
When it comes to wheels, the ABLE Rival AXS bike is equipped with the 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Allied ABLE Rival AXS has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, you won’t have a problem finding one that suits you.
