Allied ALFA SHIMANO DURA ACE 2020
2020 Road
Estimate price |
6,699$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Dura-Ace -
Suspension Rigid -
Brakes Rim
Sizing
Recommended size guide.
49cm
155cm - 163cm
49cm
155cm - 163cm
52cm
161cm - 169cm
52cm
161cm - 169cm
54cm
166cm - 175cm
54cm
166cm - 175cm
56cm
172cm - 181cm
56cm
172cm - 181cm
58cm
178cm - 186cm
58cm
178cm - 186cm
61cm
183cm - 191cm
61cm
183cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
carbon
Drivetrain
Rear Derailleur
Shimano Dura-Ace 9100
Front Derailleur
Shimano Dura-Ace 9100
Shift Levers
Shimano Dura-Ace 9100
Cassette
11-28
Crank
DURA-ACE 9100 53x39
Chain
Shimano Dura-Ace 9100
Wheels
Rims
MAVIC COSMIC UST
Cockpit
Stem
ZIPP SERVICE COURSE
Handlebar
ZIPP SERVICE COURSE
Seat
Saddle
Fabric Scoop
Seatpost
ZIPP SERVICE COURSE
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 49cm | 52cm | 52cm | 54cm | 54cm | 56cm | 56cm | 58cm | 58cm | 61cm | 61cm |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.31 mm | 1.39 mm | 1.36 mm | 1.43 mm | 1.39 mm | 1.47 mm | 1.42 mm | 1.49 mm | 1.46 mm | 1.53 mm | 1.49 mm | 1.56 mm |
| Bottom Bracket Height | 264 mm | 264 mm | 264 mm | 264 mm | 267 mm | 267 mm | 267 mm | 267 mm | 268 mm | 268 mm | 268 mm | 268 mm |
| Front Center | 570 mm | 570 mm | 575 mm | 575 mm | 581 mm | 581 mm | 592 mm | 592 mm | 607 mm | 607 mm | 614 mm | 614 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 62 mm | 62 mm | 58 mm | 59 mm | 60 mm | 59 mm | 55 mm | 55 mm | 55 mm | 55 mm | 51 mm | 51 mm |
| Stack | 498 mm | 517 mm | 520 mm | 539 mm | 536 mm | 556 mm | 557 mm | 577 mm | 585 mm | 604 mm | 605 mm | 625 mm |
| Reach | 379 mm | 373 mm | 383 mm | 378 mm | 386 mm | 379 mm | 393 mm | 388 mm | 401 mm | 395 mm | 407 mm | 401 mm |
| Top Tube Length | 510 mm | 510 mm | 534 mm | 534 mm | 545 mm | 545 mm | 562 mm | 562 mm | 580 mm | 580 mm | 598 mm | 598 mm |
| Seat Tube Angle | 75.5 ° | 75.5 ° | 74 ° | 74 ° | 73.5 ° | 73.5 ° | 73.25 ° | 73.25 ° | 73 ° | 73 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 482 mm | 482 mm | 512 mm | 512 mm | 532 mm | 532 mm | 552 mm | 552 mm | 572 mm | 572 mm | 602 mm | 602 mm |
| Head Tube Angle | 72.25 ° | 72.25 ° | 73 ° | 73 ° | 73 ° | 73 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 74 ° | 74 ° |
| Head Tube Length | 97 mm | 117 mm | 117 mm | 137 mm | 137 mm | 157 mm | 157 mm | 177 mm | 187 mm | 207 mm | 207 mm | 227 mm |
| Chainstay Length | 407 mm | 407 mm | 407 mm | 407 mm | 407 mm | 407 mm | 407 mm | 407 mm | 407 mm | 407 mm | 407 mm | 407 mm |
| Wheelbase | 966 mm | 966 mm | 971 mm | 971 mm | 978 mm | 978 mm | 989 mm | 989 mm | 1005 mm | 1005 mm | 1012 mm | 1012 mm |
| Bottom Bracket Drop | 71 mm | 71 mm | 71 mm | 71 mm | 69 mm | 69 mm | 69 mm | 69 mm | 67 mm | 67 mm | 67 mm | 67 mm |
| Standover Height | 747 mm | 747 mm | 772 mm | 772 mm | 788 mm | 788 mm | 812 mm | 812 mm | 836 mm | 836 mm | mm | mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 155 cm | 161 cm | 161 cm | 166 cm | 166 cm | 172 cm | 172 cm | 178 cm | 178 cm | 183 cm | 183 cm |
| Rider Max Height | 163 cm | 163 cm | 169 cm | 169 cm | 175 cm | 175 cm | 181 cm | 181 cm | 186 cm | 186 cm | 191 cm | 191 cm |
About this model
ALFA SHIMANO DURA ACE is an Allied Alfa model. Allied launched 38 bikes of this model so far. Take a sneak peek at all Allied Alfa bikes models from 2020, by clicking here.
Model range prices
Allied ALFA SHIMANO ULTEGRA 2020 is the cheapest bike model and costs 4999$. Allied ALFA DISC Shimano Dura Ace Di2 2020 is the most expensive one and costs 8999$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Endurance bikes average price
Our math shows that the average cost of a dependable Endurance bike is 2346$. However, even though the average price of an Endurance bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, this bike was made available in 2020 for 6699$. If we compare this with the average Endurance bike cost we notice that the price is 185.55% higher.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
The ALFA SHIMANO DURA ACE 2020 bike is equipped with 700c aluminum wheels when leaving the factory. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Allied ALFA SHIMANO DURA ACE has Rim brakes installed. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, you could spend a little extra and get a bike that has hydraulic brakes.
Sizes
There are 12 sizes available for this model. Rider height can be anywhere between 155 cm – 191 cm (5.09 ft – 6.27 ft). In conclusion, finding one for you shouldn’t be a problem.
