Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 700c -
Groupset GRX 400, GRX 600 -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aquila CX-G
Drivetrain
Rear Derailleur
Shimano GRX RD-RX400
Front Derailleur
Shimano GRX FD-RX400
Shift Levers
Shimano GRX ST-RX400
Cassette
Shimano CS-HG500-10 Speed 11-34T
Crank
Shimano FC-RX600-10 speed 48-31T
Bottom Bracket
Shimano BB-RS500-PB
Chain
Shimano CN-HG54 10 Speed
Wheels
Rims
Shimano WH-R170
Tires
Hutchinson Overide 700x38
Brakes
Brakes
hydraulicDisc
Disk Rotors
Shimano, 160mm / 140mm
Cockpit
Stem
Alloy
Handlebar
Alloy
Headset
Aquila
Seat
Saddle
Selle Italia Boost X3
Seatpost
Carbon / 27.2 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 52cm | 54cm | 56cm | 58cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.49 mm | 1.5 mm | 1.55 mm | 1.32 mm |
| Bottom Bracket Height | 282 mm | 282 mm | 282 mm | 282 mm | 282 mm |
| Front Center | 173 mm | 178 mm | 183 mm | 188 mm | 197 mm |
| Rake | -356 mm | -354 mm | -354 mm | -354 mm | -325 mm |
| Trail | 501 mm | 495 mm | 490 mm | 486 mm | 455 mm |
| Stack | 541 mm | 562 mm | 573 mm | 594 mm | 514 mm |
| Reach | 376 mm | 376 mm | 381 mm | 384 mm | 388 mm |
| Top Tube Length | 525 mm | 540 mm | 555 mm | 570 mm | 585 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 490 mm | 520 mm | 540 mm | 560 mm | 580 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 71.5 ° | 72 ° | 72 ° |
| Head Tube Length | 120 mm | 140 mm | 150 mm | 170 mm | 190 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm |
| Wheelbase | 594 mm | 600 mm | 605 mm | 611 mm | 620 mm |
| Bottom Bracket Drop | 67 mm | 67 mm | 67 mm | 67 mm | 67 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
CX-G 3 is an Aquila Cx G model. Aquila launched 15 bikes of this model so far. Take a sneak peek at all Aquila Cx G bikes models from 2022, by clicking here.
Model range prices
The most economical model, the Aquila CX-G Al 2022 has a starting price of 1590$. Aquila CX-G 1 2022 on the other hand is the most expensive at 5784$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Gravel bikes
If you want to purchase a solid Gravel bike, it is important to know that the average cost is 2462$. However, you could also get a good Gravel bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
This bike was released in 2022 and its price was 2386$. Comparing the average cost of a Gravel bike to this one, you will see that CX-G 3 price is 3.19% smaller.
CX-G 3 components
Fork material
CX-G 3 has a carbon fork, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
When leaving the production line, the CX-G 3 model has 700c aluminum wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The CX-G 3 comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
