Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ekar -
Suspension Rigid -
Drivetrain 1 × 13 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
170cm - 177cm
MD
174cm - 182cm
LG
179cm - 188cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ARC8 Eero, Carbon
Suspension Fork
ARC8 Eero, Carbon
Drivetrain
Rear Derailleur
Campagnolo Ekar 1x13
Front Derailleur
-
Shift Levers
Campagnolo Ekar 1x13
Cassette
Campagnolo EKAR 1x13 10-44
Crank
Campagnolo Ekar 1x13 38t
Bottom Bracket
PRO-Tech BSA
Chain
Campagnolo Ekar 1x13
Wheels
Rims
Front: Campagnolo Levante, Rear: Campagnolo Levante
Tires
Front: Pirelli Cinturato™ GRAVEL H 45-622, Rear: Pirelli Cinturato™ GRAVEL H 45-622
Brakes
Brakes
Campagnolo Ekar 1x13
Cockpit
Stem
ICH Stem
Handlebar
Alloy handlebar with flair
Headset
ARC8
Seat
Saddle
Selle San Marco Monza
Seatpost
Faserwerk Wuthocker 0mm Offset, 400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.51 mm | 1.52 mm | 1.54 mm | 1.56 mm |
| Bottom Bracket Height | 274 mm | 274 mm | 274 mm | 274 mm |
| Front Center | 594 mm | 603 mm | 623 mm | 644 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 74 mm | 67 mm | 67 mm | 67 mm |
| Stack | 536 mm | 559 mm | 584 mm | 609 mm |
| Reach | 355 mm | 367 mm | 379 mm | 391 mm |
| Top Tube Length | 516 mm | 536 mm | 555 mm | 574 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 510 mm | 550 mm | 570 mm | 600 mm |
| Head Tube Angle | 70 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 137 mm | 157 mm | 170 mm | 197 mm |
| Chainstay Length | 411 mm | 411 mm | 411 mm | 411 mm |
| Wheelbase | 993 mm | 1003 mm | 1023 mm | 1044 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 75 mm | 75 mm |
| Standover Height | 765 mm | 800 mm | 821 mm | 849 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 170 cm | 174 cm | 179 cm | 186 cm |
| Rider Max Height | 177 cm | 182 cm | 188 cm | cm |
Model Overview
Eero EKAR completes the Arc8 Eero model. 12 bikes variations carry this model name so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
ARC8 Eero GRX 1×12 2023 is the cheapest bike model and costs 4458$. ARC8 Eero FORCE WIDE AXS ETAP 1×12 2023 is the most expensive one and costs 6529$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Gravel bikes
According to our math, the average price for a trustworthy Gravel bike is 2462$. However, even though the average price of a Gravel bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When ARC8 released this model in 2023, its price was 5839$. Comparing this to the average Gravel bike price, we see that the price is 137.16% higher.
Eero EKAR components
Fork material
The fork on this bike is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
The Eero EKAR 2023 bike is equipped with 700c aluminum wheels when leaving the factory. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. ARC8 Eero EKAR is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
