Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Force eTAP -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
HM2X Carbon Disc 4 Belador frame built in CNT Nanotech resin and triple monocoque structure / Aero Shape Efficiency geometry and competition BGC with Power Efficiency system / Active Stay straps / asymmetric chainstays / oversized OHS steering / Always centered ISP seatpost with vibration absorption / Post Mount System / BB386 / internal wiring / frame weight gr.1100
Suspension Fork
BLADE 4 DISC
Drivetrain
Rear Derailleur
SRAM FORCE AXS
Shift Levers
SRAM FORCE AXS, HRD
Cassette
SRAM XG-1270 10-33t 12-Speed
Crank
SRAM FORCE Dub 48X35t, 170 / 172,5 / 175 mm
Bottom Bracket
BB86/BB92, press-fit
Chain
SRAM FORCE AXS
Wheels
Rims
2,000 gr
Spokes
24 (front) / 24 (rear)
Tires
Vittoria Zaffiro 25-622
Brakes
Brakes
SRAM FORCE AXS
Cockpit
Stem
Zipp Service Course Ø31.8 mm, -6º, 1-1 / 8 ", 6061 aluminum, 80/90/100/110/120 mm
Handlebar
Zipp 70 Ergo handlebar, 6061 aluminum, 70mm reach, 128mm drop, 31.8mm diameter
Seat
Saddle
Fi'zi saddle: k Antares R7, Wing Flex, K rails: ium, width 142 mm and length 275 mm
Seatpost
Aero Integrated Concept Belador, 20 mm offset, carobo
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.41 mm | 1.44 mm | 1.48 mm | 1.46 mm |
| Bottom Bracket Height | 263 mm | 266 mm | 266 mm | 268 mm | 269 mm |
| Front Center | 574 mm | 581 mm | 586 mm | 597 mm | 614 mm |
| Rake | 54 mm | 45 mm | 45 mm | 45 mm | 44 mm |
| Trail | 53 mm | 60 mm | 57 mm | 57 mm | 58 mm |
| Stack | 534 mm | 546 mm | 565 mm | 585 mm | 597 mm |
| Reach | 370.6 mm | 388 mm | 392 mm | 396 mm | 410 mm |
| Top Tube Length | 531 mm | 543 mm | 558 mm | 573 mm | 596 mm |
| Seat Tube Angle | 74 ° | 74 ° | 73.5 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 440 mm | 470 mm | 502 mm | 530 mm | 560 mm |
| Head Tube Angle | 72 ° | 72.5 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 125 mm | 138 mm | 156 mm | 180 mm | 192 mm |
| Chainstay Length | 411 mm | 411 mm | 411 mm | 411 mm | 411 mm |
| Wheelbase | 973 mm | 982 mm | 987 mm | 999 mm | 1016 mm |
| Bottom Bracket Drop | 72 mm | 70 mm | 70 mm | 67 mm | 67 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
BELADOR AERO DISC 9 is a Berria Belador model. 65 bikes variations carry this model name so far. Take a sneak peek at all Berria Belador bikes models from 2020, by clicking here.
Model range prices
Berria BELADOR 7 2020 is the most affordable bike of this model and has a price of 1910$. On the other hand, Berria BELADOR BR DISC LTD 2020, is the most expensive and costs 6688$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Endurance bikes
If you want an acceptable Endurance bike you should know that the average price is 2346$. However, this doesn’t mean that if you spend less money on an Endurance bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 4246$. If we compare this with the average Endurance bike cost we notice that the price is 80.99% higher.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork material
BELADOR AERO DISC 9 has a carbon fork, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
When it comes to wheels, the BELADOR AERO DISC 9 bike is equipped with the 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The BELADOR AERO DISC 9 comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
BELADOR AERO DISC 9 comes in 5 sizes, that range from 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, it won’t be difficult to find the right one for you.
