Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 29" -
Travel Front 100mm -
Fork Suntour XCM HLO
-
Groupset Alivio, FSA -
Suspension Hardtail -
Motor mid-drive -
Battery 500Wh -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
159cm - 170cm
MD
165cm - 177cm
LG
171cm - 184cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
MTB Alloy 29" Internal Cable Routing
Suspension Fork
SR Suntour XCM HLO 100mm
Drivetrain
Rear Derailleur
Shimano Alivio 9sp
Front Derailleur
-
Shift Levers
Shimano Alivio
Cassette
Shimano CSHG201 9sp (11-36T)
Crank
FSA 36T-170mm
Bottom Bracket
-
Chain
Shimano HG53
Pedals
-
Wheels
Front Hub
Shimano
Rear Hub
Shimano
Rims
Alloy Double Wall
Spokes
Stainless Steel
Tires
Maxxis Forekaster TPI60 29"X2,35"
Brakes
Brakes
Shimano MT200 180mm
Cockpit
Stem
BH Ahead
Handlebar
BH MTB Alloy Riser 780mm
Grips
BH Perform w/ ringlock
Headset
Tapered
Seat
Saddle
Prologo Proxim W350 Stn
Seatpost
Alloy 31,6
Motor & Battery
Motor
TS System
Battery
500Wh
Remote
BH X Display Lite
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.647 mm | 1.606 mm | 1.55 mm | 1.526 mm |
| Bottom Bracket Height | 316 mm | 316 mm | 316 mm | 316 mm |
| Stack | 657 mm | 657 mm | 662 mm | 676 mm |
| Reach | 399 mm | 409 mm | 427 mm | 443 mm |
| Top Tube Length | 594 mm | 604 mm | 623 mm | 647 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 400 mm | 450 mm | 500 mm | 520 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 140 mm | 140 mm | 145 mm | 160 mm |
| Chainstay Length | 470 mm | 470 mm | 470 mm | 470 mm |
| Wheelbase | 680 mm | 696 mm | 710 mm | 733 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 151 cm | 159 cm | 165 cm | 171 cm |
| Rider Max Height | 164 cm | 170 cm | 177 cm | 184 cm |
About this model
ATOM 29 is a Bh E Atom model. 32 e-bikes variations carry this model name so far. Check out the entire range from 2022 of this model, by clicking this link.
Model range prices
BH ATOM JET 2022 is the most affordable e-bike of this model and has a price of 2918$. On the other hand, BH ATOM LYNX 8.2 2022, is the most expensive and costs 5594$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Fitness e-bikes
Our math shows that the average cost of a dependable Fitness e-bike is 2351$. However, even if your budget is less than the average, you might still be able to get a top-quality Fitness e-bike. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
At the moment of the release date, BH ATOM 29 price was 2918$. Comparing this to the average Fitness e-bike price, we see that the price is 24.12% more expensive.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Overview of components
Fork
The fork installed on this bike is the Suntour XCM HLO model. The travel on this model is 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
The wheels on ATOM 29 are the 29″ aluminum type. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, 29″ wheels will make your e-bike react slower to obstacles you may encounter.
Brakes
For your safety, it is important to have quality breaks on your bike. BH ATOM 29 has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
ATOM 29 comes in 4 sizes, that range from 151 cm – 184 cm (4.95 ft – 6.04 ft). In short, it won’t be difficult to find the right one for you.
