Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 29" -
Travel Front 150mm -
Travel Rear 140mm -
Fork RockShox Recon Silver RL
-
Groupset Deore, Praxis -
Suspension Full -
Motor mid-drive -
Battery 500Wh -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
140 mm Full Suspension Alloy 29" Internal Cable Routing
Suspension Fork
Rock Shox Recon RL 150mm 15QR
Rear Shock
Rock Shox Deluxe Debonair
Drivetrain
Rear Derailleur
Shimano Deore 11sp
Front Derailleur
-
Shift Levers
Shimano Deore
Cassette
Shimano CSM5100 11sp (10-51T)
Crank
Praxis 34T-165mm
Chain
Shimano HG60
Wheels
Front Hub
Shimano
Rear Hub
Shimano
Rims
Alloy Double Wall
Spokes
Stainless Steel
Tires
Maxxis Forekaster TPI60 29"X2,35"
Brakes
Brakes
Shimano MT420 4 Piston 203mm
Cockpit
Stem
BH Ahead
Handlebar
BH MTB Alloy Riser 780mm
Grips
Ergon GE10
Headset
Acros AIX-322 OD46
Seat
Saddle
Prologo Proxim W350 Stn
Seatpost
Kind Shock RAGEI
Motor & Battery
Motor
TS System
Battery
500Wh
Remote
BH X Display Lite
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.57 mm | 1.51 mm | 1.45 mm |
| Bottom Bracket Height | 346 mm | 346 mm | 346 mm |
| Stack | 647 mm | 652 mm | 657 mm |
| Reach | 413 mm | 433 mm | 453 mm |
| Top Tube Length | 590 mm | 611 mm | 633 mm |
| Seat Tube Angle | 74.7 ° | 74.6 ° | 74.6 ° |
| Seat Tube Length | 420 mm | 440 mm | 480 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 140 mm | 145 mm | 150 mm |
| Chainstay Length | 467 mm | 467 mm | 467 mm |
| Wheelbase | 730 mm | 752 mm | 774 mm |
| Bottom Bracket Drop | 28 mm | 28 mm | 28 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
ATOM LYNX 8.1 is a Bh E Atom model. BH released 32 e-bikes variations of this model so far. Take a sneak peek at all Bh E Atom e-bikes models from 2022, by clicking here.
Model range prices
BH ATOM JET 2022 is the most economical model, with a starting price of 2918$. BH ATOM LYNX 8.2 2022 on the other hand costs 5594$, and is the most expensive model.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Trail e-bikes
According to our calculations, the average cost of a Trail e-bike that is reliable is 3365$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail e-bike. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
When BH released this model in 2022, its price was 4986$. If we compare this with the average Trail e-bike cost we notice that the price is 48.17% more expensive.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
ATOM LYNX 8.1 components
Fork
This e-bike has the RockShox Recon Silver RL fork installed. The fork’s travel is 150mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
The ATOM LYNX 8.1 has a rear shock with a travel of 140mm. The model Rock Shox Deluxe Debonair is the one installed in this e-bike. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
When it comes to wheels, the ATOM LYNX 8.1 e-bike is equipped with the 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, these wheels are not ideal for smaller people.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The ATOM LYNX 8.1 comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
BH ATOM LYNX 8.1 e-bike has 3 sizes, in the range of 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Every bike should have a dropper post, and this one does. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
