Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 29" -
Travel Front 100mm -
Fork Suntour
-
Groupset Deore, FSA -
Suspension Hardtail -
Motor mid-drive -
Battery 720Wh -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
MTB Alloy 29" Internal Cable Routing
Suspension Fork
SR Suntour X1 LO 100mm
Drivetrain
Rear Derailleur
Shimano Deore 10sp
Front Derailleur
-
Shift Levers
Shimano Deore
Cassette
Shimano CSM4100 10sp (11-46T)
Crank
FSA 34T-170mm
Bottom Bracket
-
Chain
Shimano HG54
Pedals
-
Wheels
Front Hub
Shimano
Rear Hub
Shimano
Rims
Alloy Double Wall
Spokes
Stainless Steel
Tires
Maxxis Forekaster TPI60 29"X2,35"
Brakes
Brakes
Shimano MT201 180mm
Cockpit
Stem
BH Ahead
Handlebar
BH MTB Alloy Riser 780mm
Grips
Ergon GE10
Headset
Tapered with adaptor
Seat
Saddle
Prologo Proxim W450 Stn
Seatpost
Alloy 31,6
Motor & Battery
Motor
TS System
Battery
720Wh
Remote
BH X Display Lite
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.61 mm | 1.55 mm | 1.53 mm |
| Bottom Bracket Height | 316 mm | 316 mm | 316 mm |
| Stack | 656 mm | 661 mm | 675 mm |
| Reach | 408 mm | 426 mm | 442 mm |
| Top Tube Length | 603 mm | 622 mm | 646 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 450 mm | 500 mm | 520 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 140 mm | 145 mm | 160 mm |
| Chainstay Length | 469 mm | 469 mm | 469 mm |
| Wheelbase | 695 mm | 709 mm | 732 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
ATOM PRO is a Bh E Atom model. BH released 32 e-bikes variations of this model so far. You can easily view all of the Bh E Atom e-bikes models from 2022, here.
Model range prices
BH ATOM JET 2022 is the most affordable e-bike of this model and has a price of 2918$. On the other hand, BH ATOM LYNX 8.2 2022, is the most expensive and costs 5594$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Fitness e-bikes average price
According to our math, the average price for a trustworthy Fitness e-bike is 2351$. However, even though the average price of a Fitness e-bike is lower, you might still be able to get a top-quality e-bike. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 3891$. In conclusion, this e-bike price is 65.5% more expensive than the price of the average Fitness e-bike.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
ATOM PRO components
Fork
BH ATOM PRO 2022 e-bike is equipped with the Suntour fork, and has 100mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
When it comes to wheels, the ATOM PRO e-bike is equipped with the 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, the 29″ wheels will add a little more weight to the e-bike itself.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The ATOM PRO comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
This e-bike is available in 3 sizes. They vary from 158 cm – 187 cm (5.18 ft – 6.14 ft). In short, you can easily find one that suits you.
