Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Travel Front 100mm -
Fork Suntour XCR 34
-
Groupset Deore, FSA -
Suspension Hardtail -
Motor mid-drive -
Battery 720Wh -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Sport Alloy 27,5" Internal Cable Routing
Suspension Fork
SR Suntour XCR34 LO 100mm 15QR
Drivetrain
Rear Derailleur
Shimano Deore 11sp
Front Derailleur
-
Shift Levers
Shimano Deore
Cassette
Shimano CSM5100 11sp (11-51T)
Crank
FSA 38T-170mm
Chain
Shimano HG60
Wheels
Front Hub
BH
Rear Hub
BH
Rims
Race Face Ar 30 TR
Spokes
Stainless Steel
Tires
Schwalbe Super Moto-X 27,5"X2,4
Brakes
Brakes
Shimano MT420 4 Piston 203mm
Cockpit
Stem
Ergotec Adjustable
Handlebar
BH Lite Riser 720mm
Grips
Ergon GP10
Headset
Acros AZX-581 BL.
Seat
Saddle
Selle Royal eZone
Seatpost
BH Lite Alloy 31,6
Motor & Battery
Motor
X System
Battery
720Wh
Remote
BH X Display
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.42 mm | 1.38 mm | 1.38 mm |
| Bottom Bracket Height | 315 mm | 315 mm | 315 mm | 315 mm |
| Stack | 611 mm | 620 mm | 630 mm | 648 mm |
| Reach | 423 mm | 438 mm | 458 mm | 468 mm |
| Top Tube Length | 588 mm | 605 mm | 627 mm | 643 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 420 mm | 450 mm | 480 mm | 510 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 140 mm |
| Chainstay Length | 473 mm | 473 mm | 473 mm | 473 mm |
| Wheelbase | 683 mm | 702 mm | 725 mm | 742 mm |
| Wheels | 650 | 650 | 650 | 650 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
ATOMX CROSS PRO is part of the Bh E Atomx model. There are 58 e-bikes that carry this model name. You can easily view all of the Bh E Atomx e-bikes models from 2022, here.
Model range prices
BH ATOMX PRO 2022 is the most affordable e-bike of this model and has a price of 5229$. On the other hand, BH ATOMX LYNX CARBON PRO 9.9 2022, is the most expensive and costs 10703$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Hybrid e-bikes
According to our calculations, the average cost of a Hybrid e-bike that is reliable is 2480$. However, this doesn’t mean that if you spend less money on a Hybrid e-bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
This e-bike was released in 2022 and its price was 5473$. Comparing this to the average Hybrid e-bike price, we see that the price is 120.69% higher.
Internal Cable Routing
It’s also important to mention the internal cable routing that this e-bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
ATOMX CROSS PRO components
Fork
The Suntour XCR 34 is included from the factory. It has a travel distance of 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
As for the wheels, BH ATOMX CROSS PRO 2022, has a aluminum model. 650b wheels make a great choice if you want to sacrifice speed for comfort. However, if speed is what you’re after, 700c wheels are a better fit.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
ATOMX CROSS PRO comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
