Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset 105, FSA -
Suspension Rigid -
Motor mid-drive -
Battery 540Wh -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Race Alloy 28" Internal Cable Routing
Suspension Fork
BH Race Carbon ACR
Drivetrain
Rear Derailleur
Shimano 105 11sp
Front Derailleur
Shimano 105
Shift Levers
Shimano 105
Cassette
Shimano 105 11sp (11-34T)
Crank
FSA 50/34T
Bottom Bracket
-
Chain
Shimano HG70
Pedals
-
Wheels
Front Hub
Shimano
Rear Hub
Shimano
Rims
Shimano RS171 TR
Spokes
Stainless Steel
Tires
Hutchinson Nitro 2 700X28
Brakes
Brakes
Front: Shimano 105 160mm, Rear: Shimano 105 160mm
Cockpit
Stem
BH Lite Ahead
Handlebar
FSA Energy SCR Compact
Grips
Bar Tape
Headset
FSA ACR
Seat
Saddle
Prologo Scratch-RS
Seatpost
Lite Alloy 27,2
Motor & Battery
Motor
NR System
Battery
540Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.43 mm | 1.44 mm |
| Bottom Bracket Height | 270 mm | 270 mm | 270 mm |
| Stack | 546 mm | 563 mm | 579 mm |
| Reach | 390 mm | 393 mm | 403 mm |
| Top Tube Length | 547 mm | 564 mm | 585 mm |
| Seat Tube Angle | 74 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 470 mm | 490 mm | 510 mm |
| Head Tube Angle | 72 ° | 73 ° | 73 ° |
| Head Tube Length | 145 mm | 160 mm | 175 mm |
| Chainstay Length | 422 mm | 422 mm | 422 mm |
| Wheelbase | 596 mm | 599 mm | 609 mm |
| Bottom Bracket Drop | 66 mm | 66 mm | 66 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
CORE RACE 1.2 is a Bh E Core model. 33 e-bikes variations carry this model name so far. You can get a glimpse at all models from 2022, by clicking on this link.
Model range prices
The most economical model, the BH CORE CITY WAVE 2022 has a starting price of 3283$. BH CORE RACE CARBON PRO 1.8 2022 on the other hand is the most expensive at 8878$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Race e-bikes
If you want an acceptable Race e-bike you should know that the average price is 4156$. However, even if your budget is less than the average, you might still be able to get a top-quality Race e-bike. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
When BH released this model in 2022, its price was 4743$. Doing a quick comparison, we notice that CORE RACE 1.2 price is 14.12% more expensive than the average cost of a Race e-bike.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork material
When it comes to the fork, this e-bike has a carbon one, so, it’s a great addition to the e-bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
As for the wheels, BH CORE RACE 1.2 2022, has a 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. BH CORE RACE 1.2 has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 158 cm – 187 cm (5.18 ft – 6.14 ft). In short, it won’t be difficult to find the right one for you.
