Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Force eTap -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
51cm
165cm - 174cm
54cm
172cm - 180cm
56cm
178cm - 186cm
58cm
184cm - 192cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kaius 01 Premium Carbon with Aerocore Design | ICS Technology, Stealth Cable Routing | Integrated Aerocore Bottle Cages | Stealth Dropout Design | TCC Race Compliance Level | PF86 Bottom Bracket | Flat Mount Disc | 12x142mm Thru-Axle
Suspension Fork
Kaius 01 Premium Carbon | ICS Technology, Stealth Cable Routing | TCC Race Compliance Level | Stealth Dropout Design | Flat Mount Disc | 12x100mm Thru-Axle
Drivetrain
Rear Derailleur
SRAM Force eTap AXS WIDE
Front Derailleur
SRAM Force eTap AXS WIDE
Shift Levers
SRAM Force eTap AXS HRD
Cassette
SRAM Force AXS XG-1270 10-36T
Crank
SRAM Force DUB WIDE 43-30T Power Meter
Bottom Bracket
BB86/BB92, press-fit
Chain
SRAM Force 12 Speed
Wheels
Front Hub
CG39 (Star Ratchet System, Straightpull Design)
Rear Hub
CG39 (Star Ratchet System, Straightpull Design)
Rims
CG39 (39mm rim height, 25mm inner width)
Tires
Pirelli Cinturato Gravel H, 40mm
Brakes
Brakes
Hydraulic Disc
Cockpit
Stem
BMC ICS2 - Integrated Cockpit Design
Handlebar
Easton EC70 AX Carbon
Seat
Saddle
Fizik Vento Argo R3 - 140mm
Seatpost
Kaius 01 Premium Carbon D-Shaped Seatpost | 15mm Offset | D-Fender Compatible
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 51cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.308 mm | 1.335 mm | 1.372 mm | 1.407 mm | 1.451 mm | 1.498 mm |
| Bottom Bracket Height | 269 mm | 269 mm | 269 mm | 269 mm | 269 mm | 269 mm |
| Front Center | 596 mm | 610 mm | 608 mm | 619 mm | 632 mm | 644 mm |
| Rake | 50 mm | 50 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 66 mm | 66 mm | 68 mm | 68 mm | 68 mm | 68 mm |
| Stack | 510 mm | 530 mm | 550 mm | 570 mm | 595 mm | 620 mm |
| Reach | 390 mm | 397 mm | 401 mm | 405 mm | 410 mm | 414 mm |
| Top Tube Length | 546 mm | 559 mm | 569 mm | 579 mm | 592 mm | 604 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 428 mm | 452 mm | 468 mm | 493 mm | 513 mm | 533 mm |
| Head Tube Angle | 71 ° | 71 ° | 72 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 85 mm | 106 mm | 123 mm | 144 mm | 170 mm | 196 mm |
| Chainstay Length | 420 mm | 420 mm | 420 mm | 420 mm | 420 mm | 420 mm |
| Wheelbase | 1003 mm | 1017 mm | 1015 mm | 1026 mm | 1039 mm | 1051 mm |
| Bottom Bracket Drop | 80 mm | 80 mm | 80 mm | 80 mm | 80 mm | 80 mm |
| Standover Height | 684 mm | 722 mm | 756 mm | 780 mm | 798 mm | 818 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Max Height | 167 cm | 174 cm | 180 cm | 186 cm | 192 cm | cm |
Model Overview
Kaius 01 TWO is a Bmc Kaius model. 6 bikes variations carry this model name so far. You can get a glimpse at all models from 2024, by clicking on this link.
Model range prices
The most economical model, the BMC Kaius 01 THREE 2024 has a starting price of 6352$. BMC Kaius 01 LTD 2024 on the other hand is the most expensive at 12706$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Gravel bikes
Our math shows that the average cost of a dependable Gravel bike is 2462$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Gravel bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
At the moment of the release date, BMC Kaius 01 TWO price was 9529$. If we compare this with the average Gravel bike cost we notice that the price is 287.04% more expensive.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork material
When it comes to the fork, this bike has a carbon one, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
When leaving the production line, the Kaius 01 TWO model has 700c aluminum wheels. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Kaius 01 TWO comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
