Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 130mm -
Travel Rear 130mm -
Fork RockShox Pike RC
-
Groupset XT, Race Face -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
02 Carbon (F), Al-13 Triple-butted aluminum (R)
Suspension Fork
RockShox Pike RC (120/130mm)***
Rear Shock
Fox Float DPS, Performance Elite, Evol, Remote (120/130mm)***
Drivetrain
Rear Derailleur
Shimano XT, Shadow Plus
Front Derailleur
-
Shift Levers
Shimano XT
Cassette
Shimano XT, 11-46T
Crank
RaceFace Turbine Cinch 32T
Bottom Bracket
SRAM PF92
Chain
KMC X-11EL-1
Chain Guide
N/A
Wheels
Front Hub
DT Swiss M1700 Spline
Rear Hub
DT Swiss M1700 Spline
Rims
DT Swiss M700 Spline 30**
Spokes
DT Swiss
Tires
Maxxis Forekaster EXO, 27,5 or 29x2.35
Brakes
Brakes
Shimano XT (180/180mm)
Brake Levers
Shimano XT
Cockpit
Stem
BMC AMSM 02
Handlebar
BMC MRB 02, 760mm
Seat
Saddle
WTB Volt Race
Seatpost
BMC Trailsync, 120mm*
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.43 mm | 1.37 mm | 1.38 mm | 1.37 mm |
| Bottom Bracket Height | 352 mm | 337 mm | 352 mm | 337 mm | 337 mm |
| Front Center | 685 mm | 704 mm | 712 mm | 728 mm | 748 mm |
| Rake | 46 mm | 51 mm | 46 mm | 51 mm | 51 mm |
| Trail | 98 mm | 98 mm | 98 mm | 98 mm | 98 mm |
| Stack | 577 mm | 603 mm | 588 mm | 613 mm | 628 mm |
| Reach | 406 mm | 423 mm | 429 mm | 443 mm | 458 mm |
| Top Tube Length | 580 mm | 604 mm | 606 mm | 627 mm | 646 mm |
| Seat Tube Angle | 73.25 ° | 73.25 ° | 73.25 ° | 73.25 ° | 73.25 ° |
| Seat Tube Length | 410 mm | 440 mm | 430 mm | 480 mm | 510 mm |
| Head Tube Angle | 67.5 ° | 68.25 ° | 67.5 ° | 68.25 ° | 68.25 ° |
| Head Tube Length | 110 mm | 105 mm | 120 mm | 115 mm | 135 mm |
| Chainstay Length | 423 mm | 438 mm | 423 mm | 438 mm | 438 mm |
| Wheelbase | 1104 mm | 1138 mm | 1131 mm | 1162 mm | 1182 mm |
| Bottom Bracket Drop | 22 mm | 37 mm | 22 mm | 37 mm | 37 mm |
| Standover Height | 688 mm | 727 mm | 715 mm | 745 mm | 766 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Speedfox 02 TWO is part of the Bmc Speedfox model. 28 bikes variations carry this model name so far. You can easily view all of the Bmc Speedfox bikes models from 2018, here.
Model range prices
BMC Speedfox 03 THREE 2018 is the cheapest bike model and costs 2199$. BMC Speedfox 01 ONE 2018 is the most expensive one and costs 7499$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Trail bikes
Our math shows that the average cost of a dependable Trail bike is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 5199$. If we compare this with the average Trail bike cost we notice that the price is 88.23% higher.
Overview of components
Fork
The fork installed on this bike is the RockShox Pike RC model. The travel on this model is 130mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
As for the rear shock, this bike has the Fox Float DPS model, with a travel of 130mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
The Speedfox 02 TWO 2018 bike is equipped with 29″ aluminum wheels when leaving the factory. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
BMC Speedfox 02 TWO bike has 5 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
A dropper post is included with the Speedfox 02 TWO. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
