Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 130mm -
Travel Rear 130mm -
Fork RockShox Recon Silver RL
-
Groupset NX -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
03 Alloy, Al-13 Triple-butted aluminum (F&R)
Suspension Fork
RockShox Recon RL (120/130mm)***
Rear Shock
Fox Float DPS, Performance, Evol, (120/130mm)***
Drivetrain
Rear Derailleur
SRAM NX
Front Derailleur
-
Shift Levers
SRAM NX
Cassette
SRAM PG 1130 11-42T
Crank
SRAM NX 30T
Bottom Bracket
BSA 73mm
Chain
KMC X-11EL-1
Chain Guide
N/A
Pedals
N/A
Wheels
Front Hub
Shimano Deore
Rear Hub
Shimano Deore
Rims
Alex MD30**
Tires
Maxxis Forekaster EXO, 27,5 or 29x2.35
Brakes
Brakes
Shimano BR-MT500 (180/180mm)
Brake Levers
Shimano BR-MT500
Cockpit
Stem
BMC AMSM 02
Handlebar
BMC MRB 03, 760mm
Seat
Saddle
WTB Volt Sport
Seatpost
RaceFace Aeffect Dropper 125/150mm***
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.43 mm | 1.37 mm | 1.38 mm | 1.37 mm |
| Bottom Bracket Height | 352 mm | 337 mm | 352 mm | 337 mm | 337 mm |
| Front Center | 685 mm | 704 mm | 712 mm | 728 mm | 748 mm |
| Rake | 46 mm | 51 mm | 46 mm | 51 mm | 51 mm |
| Trail | 98 mm | 90 mm | 98 mm | 90 mm | 90 mm |
| Stack | 577 mm | 603 mm | 588 mm | 613 mm | 628 mm |
| Reach | 406 mm | 423 mm | 429 mm | 443 mm | 458 mm |
| Top Tube Length | 580 mm | 604 mm | 606 mm | 627 mm | 646 mm |
| Seat Tube Angle | 73.25 ° | 73.25 ° | 73.25 ° | 73.25 ° | 73.25 ° |
| Seat Tube Length | 410 mm | 440 mm | 430 mm | 480 mm | 510 mm |
| Head Tube Angle | 67.5 ° | 68.25 ° | 67.5 ° | 68.25 ° | 68.25 ° |
| Head Tube Length | 110 mm | 105 mm | 120 mm | 115 mm | 135 mm |
| Chainstay Length | 423 mm | 438 mm | 423 mm | 438 mm | 438 mm |
| Wheelbase | 1104 mm | 1138 mm | 1131 mm | 1162 mm | 1182 mm |
| Bottom Bracket Drop | 22 mm | 37 mm | 22 mm | 37 mm | 37 mm |
| Standover Height | 688 mm | 727 mm | 715 mm | 745 mm | 766 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 180 cm | 189 cm | 199 cm |
About this model
Speedfox 03 TWO completes the Bmc Speedfox model. 28 bikes variations carry this model name so far. Check out the entire range from 2018 of this model, by clicking this link.
Model range prices
BMC Speedfox 03 THREE 2018 is the most economical model, with a starting price of 2199$. BMC Speedfox 01 ONE 2018 on the other hand costs 7499$, and is the most expensive model.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Trail bikes average price
Our math shows that the average cost of a dependable Trail bike is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When BMC released this model in 2018, its price was 2699$. Doing a quick comparison, we notice that Speedfox 03 TWO price is 2.33% lower than the average cost of a Trail bike.
Speedfox 03 TWO components
Fork
The fork installed on this bike is the RockShox Recon Silver RL model. The travel on this model is 130mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
The Speedfox 03 TWO has a rear shock with a travel of 130mm. The model Fox Float DPS is the one installed in this bike. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
When leaving the production line, the Speedfox 03 TWO model has 29″ aluminum wheels. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
For your safety, it is important to have quality breaks on your bike. BMC Speedfox 03 TWO has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
Dropper post
Every bike should have a dropper post, and this one does. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
