Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Force eTap -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
51cm
165cm - 174cm
54cm
172cm - 180cm
56cm
178cm - 186cm
58cm
184cm - 192cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Teammachine R 01 Premium Carbon with Aerocore Design | ICS Technology, Stealth Cable Routing | Integrated Aerocore Bottle Cages | Stealth Dropout Design | PF86 Bottom Bracket | Flat Mount Disc | 12x142mm Thru-Axle
Suspension Fork
Teammachine R 01 Premium Carbon | ICS Technology | Stealth Cable Routing | Stealth Dropout Design | Flat Mount Disc | 12x100mm Thru-Axle
Drivetrain
Rear Derailleur
SRAM Force eTap AXS
Front Derailleur
SRAM Force eTap AXS
Shift Levers
SRAM Force eTap AXS
Cassette
SRAM Force XG-1270 10-28T
Crank
SRAM Force 48-35T Power Meter
Bottom Bracket
BB86/BB92, press-fit
Chain
SRAM FORCE 12 Speed
Wheels
Front Hub
CRD-501 SL
Rear Hub
CRD-501 SL
Rims
CRD-501 SL Carbon - Tubeless Ready - 50mm
Tires
Pirelli P ZERO Race TLR 26mm
Brakes
Brakes
Hydraulic Disc
Cockpit
Handlebar
ICS Carbon Aero | One-Piece Full Carbon Cockpit
Seat
Saddle
Fizik Argo Vento R3 (140mm)
Seatpost
Teammachine R 01 Premium Carbon Seatpost | 10mm Offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 51cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.37 mm | 1.397 mm | 1.416 mm | 1.433 mm | 1.448 mm | 1.487 mm |
| Bottom Bracket Height | 267 mm | 267 mm | 267 mm | 267 mm | 267 mm | 267 mm |
| Front Center | 568 mm | 586 mm | 589 mm | 599 mm | 614 mm | 630 mm |
| Rake | 48 mm | 48 mm | 43 mm | 43 mm | 43 mm | 43 mm |
| Trail | 63 mm | 63 mm | 63 mm | 63 mm | 63 mm | 63 mm |
| Stack | 504 mm | 528 mm | 548 mm | 563 mm | 582 mm | 608 mm |
| Reach | 368 mm | 378 mm | 387 mm | 393 mm | 402 mm | 409 mm |
| Top Tube Length | 522 mm | 532 mm | 552 mm | 562 mm | 582 mm | 598 mm |
| Seat Tube Angle | 74 ° | 74 ° | 73.5 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 418 mm | 463 mm | 499 mm | 519 mm | 541 mm | 570 mm |
| Head Tube Angle | 71.5 ° | 71.5 ° | 72.3 ° | 72.3 ° | 72.3 ° | 72.3 ° |
| Head Tube Length | 108 mm | 133 mm | 149 mm | 165 mm | 185 mm | 211 mm |
| Chainstay Length | 410 mm | 410 mm | 410 mm | 410 mm | 410 mm | 410 mm |
| Wheelbase | 968 mm | 986 mm | 989 mm | 999 mm | 1015 mm | 1030 mm |
| Bottom Bracket Drop | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Max Height | 167 cm | 174 cm | 180 cm | 186 cm | 192 cm | cm |
Model Overview
Teammachine R 01 THREE is part of the Bmc Teammachine model. BMC released 163 bikes variations of this model so far. Check out the entire range from 2024 of this model, by clicking this link.
Model range prices
BMC Teammachine R 01 MOD 2024 is the most economical model, with a starting price of 6352$. BMC Teammachine R 01 LTD 2024 on the other hand costs 15883$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Race bikes average price
If you want to purchase a solid Race bike, it is important to know that the average cost is 3350$. However, you could also get a good Race bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 10059$. Doing a quick comparison, we notice that Teammachine R 01 THREE price is 200.27% more expensive than the average cost of a Race bike.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
The Teammachine R 01 THREE 2024 bike is equipped with 700c carbon wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The Teammachine R 01 THREE has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
