Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 160mm -
Travel Rear 150mm -
Fork RockShox Yari RC
-
Groupset XT, Race Face -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Al-13 Premium Triple-butted aluminum (F&R)
Suspension Fork
Rock Shox Yari RC, Solo Air (160mm)
Rear Shock
Cane Creek DB Inline (150mm)
Drivetrain
Rear Derailleur
Shimano XT, Shadow Plus
Front Derailleur
-
Shift Levers
Shimano XT
Cassette
Shimano XT, 11-46T
Crank
RaceFace Aeffect SL DM, 32T
Bottom Bracket
BB30
Chain
KMC X-11EL-1
Chain Guide
N/A
Pedals
N/A
Wheels
Front Hub
RaceRace Aeffect R
Rear Hub
RaceRace Aeffect R
Rims
RaceFace Aeffect R 30**
Tires
Maxxis Minion DHF EXO/3C, 2.35 (F) / Maxxis Minion DHR EXO/3C, 2.3 (R)
Brakes
Brakes
Shimano XT (203/203mm)*
Brake Levers
Shimano XT
Cockpit
Stem
BMC AMSM 02, 45mm
Handlebar
BMC MRB 02, 780mm
Seat
Saddle
WTB Volt Race
Seatpost
RaceFace Turbine Dropper 150mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.488 mm | 1.414 mm | 1.346 mm |
| Bottom Bracket Height | 344 mm | 344 mm | 344 mm |
| Front Center | 712 mm | 739 mm | 766 mm |
| Rake | 51 mm | 51 mm | 51 mm |
| Trail | 101 mm | 101 mm | 101 mm |
| Stack | 610 mm | 615 mm | 619 mm |
| Reach | 410 mm | 435 mm | 460 mm |
| Top Tube Length | 585 mm | 611 mm | 638 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 400 mm | 440 mm | 480 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 90 mm | 95 mm | 100 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1045 mm | 1173 mm | 1200 mm |
| Bottom Bracket Drop | 30 mm | 30 mm | 30 mm |
| Standover Height | 725 mm | 735 mm | 745 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
Trailfox 03 ONE completes the Bmc Trailfox model. There are 7 bikes that carry this model name. You can easily view all of the Bmc Trailfox bikes models from 2018, here.
Model range prices
The most economical model, the BMC Trailfox 03 TWO 2018 has a starting price of 3499$. BMC Trailfox 02 ONE 2018 on the other hand is the most expensive at 5299$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Enduro bikes average price
Our math shows that the average cost of a dependable Enduro bike is 3599$. However, this doesn’t mean that if you spend less money on an Enduro bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
At the moment of the release date, BMC Trailfox 03 ONE price was 4299$. Comparing this to the average Enduro bike price, we see that the price is 19.45% more expensive.
Overview of components
Fork
The fork installed on this bike is the RockShox Yari RC model. The travel on this model is 160mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
As for the rear shock, this bike has the Cane Creek DB Inline (150mm) model, with a travel of 150mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels
The Trailfox 03 ONE 2018 bike is equipped with 29″ aluminum wheels when leaving the factory. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
For your safety, it is important to have quality breaks on your bike. BMC Trailfox 03 ONE has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
BMC Trailfox 03 ONE bike has 3 sizes, in the range of 158 cm – 187 cm (5.18 ft – 6.14 ft). In short, you can easily find one that suits you.
Dropper post
Every bike should have a dropper post, and this one does. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
