Boardman CXR 9.0 2019
2019 Road
Estimate price |
2,710$
Weight | 8.8 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 700c -
Groupset Apex 1 -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
167cm - 173cm
SM
171cm - 178cm
MD
176cm - 184cm
LG
182cm - 190cm
XL
188cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
CXR - C10 Carbon
Suspension Fork
Boardman CXR C10 Carbon Tapered Steerer, 12mm Thru-Axle
Drivetrain
Rear Derailleur
SRAM Apex 1
Shift Levers
SRAM Apex 1
Cassette
SRAM Apex 11-36
Crank
SRAM Apex 1 - BB30 40T
Bottom Bracket
FSA BB-PF30
Chain
SRAM PC-1110
Wheels
Front Hub
12x100mm front, 12x142mm rear
Rear Hub
12x100mm front, 12x142mm rear
Rims
Boardman CXR Elite Five
Tires
33mm Clement MXP Tubeless
Brakes
Brakes
SRAM Apex Hydraulic
Cockpit
Stem
Boardman Alloy - 6° rise
Handlebar
Boardman Alloy
Headset
FSA, No.42
Seat
Saddle
Fizik Tundra M7
Seatpost
Boardman Elite Carbon - 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.36 mm | 1.42 mm | 1.47 mm | 1.51 mm | 1.53 mm |
| Bottom Bracket Height | 277 mm | 277 mm | 279 mm | 279 mm | 279 mm |
| Front Center | 597 mm | 595 mm | 596 mm | 601 mm | 610 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 77 mm | 67 mm | 64 mm | 62 mm | 58 mm |
| Stack | 521 mm | 545 mm | 564 mm | 585 mm | 606 mm |
| Reach | 382 mm | 385 mm | 384 mm | 388 mm | 396 mm |
| Top Tube Length | 521 mm | 536 mm | 551 mm | 566 mm | 581 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 520 mm | 540 mm | 560 mm | 580 mm | 600 mm |
| Head Tube Angle | 70 ° | 71.5 ° | 72 ° | 72.5 ° | 73 ° |
| Head Tube Length | 100 mm | 120 mm | 140 mm | 160 mm | 180 mm |
| Chainstay Length | 426 mm | 426 mm | 426 mm | 426 mm | 426 mm |
| Wheelbase | 1014 mm | 1012 mm | 1013 mm | 1018 mm | 1028 mm |
| Bottom Bracket Drop | 67 mm | 67 mm | 65 mm | 65 mm | 65 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 167 cm | 171 cm | 176 cm | 182 cm | 188 cm |
| Rider Max Height | 173 cm | 178 cm | 184 cm | 190 cm | 200 cm |
Model Overview
CXR 9.0 is a Boardman Cxr model. There are 8 bikes that carry this model name. Check out the entire range from 2019 of this model, by clicking this link.
Model range prices
Boardman CXR 8.9 2019 is the most affordable bike of this model and has a price of 1216$. On the other hand, Boardman CXR 9.4 2019, is the most expensive and costs 3892$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Cyclocross bikes average price
According to our calculations, the average cost of a Cyclocross bike that is reliable is 2012$. However, even though the average price of a Cyclocross bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 2433$. Comparing the average cost of a Cyclocross bike to this one, you will see that CXR 9.0 price is 20.92% more expensive.
Cyclocross bikes average weight
Cyclocross bikes weigh an average of 8.79 kg (19.38 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
Weighing 8.8 kg (19.4 lbs), the CXR 9.0 model is slightly heavier than average. In other words, this model is 0.11% heavier than the average Cyclocross bike.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
When leaving the production line, the CXR 9.0 model has 700c aluminum wheels. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The CXR 9.0 has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
This bike is available in 5 sizes. They vary from 167 cm – 200 cm (5.48 ft – 6.56 ft). In conclusion, it won’t take much to find one that’s right for you.
