Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame aluminium -
Wheels 27.5" -
Travel Front 100mm -
Fork Suntour XCR
-
Groupset XT, Deore -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
165cm - 176cm
MD
174cm - 184cm
LG
182cm - 193cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Canyon Grand Canyon AL, Material: Aluminium (AL)
Suspension Fork
SR Suntour XCR, Travel: 100 mm, Fork steer tube diameter: 1 1/8"
Drivetrain
Rear Derailleur
Shimano Deore XT M8100 12speed, Precise 1x12 drivetrain.
Shift Levers
Shimano Deore M6100 12s, Right shift lever. Shifts up to 3 gears at a time.
Cassette
Shimano Deore M6100 12speed, Cassette packed with trickle-down performance features. Hyperglide+ tech provides fast, smooth shifting. Beam spider construction cuts weights and boosts stiffness. Gear range: 10-51.
Crank
Shimano MT611 30T, Number of chainrings: 1
Bottom Bracket
Shimano BSA BB52
Chain
Shimano CN-M6100 12s
Wheels
Rims
Iridium 25 | Shimano MT401 S12, Rotor Mount: Center Lock | Iridium 25 | Shimano MT400, Rotor Mount: Center Lock
Tires
Schwalbe Rapid Rob 2.25'', Casing: K-Guard | Schwalbe Tough Tom 2.25"
Brakes
Brakes
Shimano MT400
Disk Rotors
Shimano RT10, Disc Mount: Centerlock
Cockpit
Stem
Iridium, Clamping Diameter: 31,8 mm
Handlebar
Iridium Flatbar, Material: Aluminium, Rise: 5 mm
Grips
Canyon push-on Grips, Our grips for confidence building control on the bars.
Seat
Saddle
Iridium Trail
Seatpost
Iridium, Clamp diameter: 30,9 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.44 mm | 1.44 mm | 1.41 mm | 1.4 mm |
| Bottom Bracket Height | 308 mm | 308 mm | 309 mm | 309 mm | 309 mm |
| Front Center | 665 mm | 686 mm | 730 mm | 756 mm | 787 mm |
| Rake | 44 mm | 44 mm | 55 mm | 55 mm | 55 mm |
| Trail | 96 mm | 96 mm | 96 mm | 96 mm | 96 mm |
| Stack | 588 mm | 597 mm | 627 mm | 641 mm | 668 mm |
| Reach | 399 mm | 416 mm | 436 mm | 456 mm | 476 mm |
| Top Tube Length | 567 mm | 587 mm | 615 mm | 639 mm | 667 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 350 mm | 395 mm | 440 mm | 485 mm | 545 mm |
| Head Tube Angle | 68 ° | 68 ° | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 90 mm | 100 mm | 100 mm | 115 mm | 145 mm |
| Chainstay Length | 424 mm | 424 mm | 429 mm | 434 mm | 439 mm |
| Wheelbase | 1085 mm | 1106 mm | 1151 mm | 1182 mm | 1218 mm |
| Bottom Bracket Drop | 47 mm | 47 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 731 mm | 761 mm | 814 mm | 842 mm | 880 mm |
| Front Travel | 100 mm | 100 mm | 100 mm | 100 mm | 100 mm |
| Wheels | 27" | 27" | 29" | 29" | 29" |
| Rider Max Height | 167 cm | 176 cm | 184 cm | 193 cm | cm |
Model Overview
Grand Canyon 6 is part of the Canyon Grand Canyon model. Canyon launched 49 bikes of this model so far. You can easily view all of the Canyon Grand Canyon bikes models from 2022, here.
Model range prices
The most economical model, the Canyon Grand Canyon 5 WMN 2022 has a starting price of 901$. Canyon Grand Canyon 9 2022 on the other hand is the most expensive at 1910$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Crosscountry bikes average price
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2022 for 1114$. In conclusion, this bike price is 71.01% lower than the price of the average Crosscountry bike.
Grand Canyon 6 components
Fork
This bike has the Suntour XCR fork installed. The fork’s travel is 100mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels size
As for the wheels, Canyon Grand Canyon 6 2022, has a 27.5″ aluminum model. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
