Canyon Grand 6 2023
2023 Mountain
Estimate price |
1,203$
Weight | 13.76 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Travel Front 100mm -
Fork Suntour XCR
-
Groupset XT, Deore -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
165cm - 176cm
MD
174cm - 184cm
LG
182cm - 193cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Canyon Grand Canyon AL, Material: Aluminium (AL)
Suspension Fork
SR Suntour XCR, Travel: 100 mm, Fork steer tube diameter: 1 1/8", Weight: 2.46 kg
Drivetrain
Rear Derailleur
Shimano DEORE XT M8100, Cage length: long, Weight: 286 g
Shift Levers
Shimano Deore M6100 12s
Cassette
Shimano DEORE M6100, Number of sprockets: 12 | Shimano CS-M6100 Deore 12-speed Cassette 10-51
Crank
Shimano MT611 30T, Number of chainrings: 1
Bottom Bracket
Shimano BSA BB52, Bottom bracket standard: BSA HT2 68/73, Weight: 98 g
Chain
Shimano CN-M6100 | Shimano SM-CN910 12-speed Quick-Link Chain Connector | Shimano CN-M6100 Deore 12-speed Chain 138 Links
Wheels
Rims
Iridium 25 | Shimano MT401 S12, Rotor mount: Center Lock, Weight: 950 g | Iridium 25 | Shimano MT400, Rotor mount: Center Lock, Weight: 850 g
Tires
Schwalbe Rapid Rob 2.25'', Width: 2.25" | Schwalbe Tough Tom 2.25"
Brakes
Brakes
Shimano MT400
Cockpit
Stem
Iridium, Fork steer tube diameter: 1 1/8", Clamping diameter: 31,8 mm
Handlebar
Iridium Flatbar, Clamping diameter: 31,8 mm, Width: 740 mm, Rise: 5 mm
Grips
Canyon push-on Grips
Seat
Saddle
Iridium Trail
Seatpost
Iridium, Clamp diameter: 30,9 mm, Material: Aluminium (AL), Weight: 280 g
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.44 mm | 1.44 mm | 1.41 mm | 1.4 mm |
| Bottom Bracket Height | 308 mm | 308 mm | 309 mm | 309 mm | 309 mm |
| Front Center | 665 mm | 686 mm | 730 mm | 756 mm | 787 mm |
| Rake | 44 mm | 58 mm | 55 mm | 55 mm | 55 mm |
| Trail | 96 mm | 81 mm | 96 mm | 96 mm | 96 mm |
| Stack | 588 mm | 584 mm | 627 mm | 641 mm | 668 mm |
| Reach | 399 mm | 406 mm | 436 mm | 456 mm | 476 mm |
| Top Tube Length | 567 mm | 587 mm | 615 mm | 639 mm | 667 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 350 mm | 395 mm | 440 mm | 485 mm | 545 mm |
| Head Tube Angle | 68 ° | 68 ° | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 90 mm | 100 mm | 100 mm | 115 mm | 145 mm |
| Chainstay Length | 424 mm | 424 mm | 429 mm | 434 mm | 439 mm |
| Wheelbase | 1085 mm | 1106 mm | 1151 mm | 1182 mm | 1218 mm |
| Bottom Bracket Drop | 47 mm | 47 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 731 mm | 761 mm | 814 mm | 842 mm | 880 mm |
| Front Travel | 100 mm | 100 mm | 100 mm | 100 mm | 100 mm |
| Wheels | 27" | 27" | 29" | 29" | 29" |
| Rider Max Height | 167 cm | 176 cm | 184 cm | 193 cm | cm |
About this model
Grand Canyon 6 is a Canyon Grand Canyon model. 49 bikes variations carry this model name so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Canyon Grand Canyon 5 2023 is the cheapest bike model and costs 699$. Canyon Grand Canyon 9 2023 is the most expensive one and costs 1910$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Crosscountry bikes
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
This bike was released in 2023 and its price was 1114$. Comparing this to the average Crosscountry bike price, we see that the price is 71.01% smaller.
Crosscountry bikes average weight
On a deeper look, we notice that the average weight of a Crosscountry bike is 12.4 kg (27.34 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
With a weight of 13.76 kg (30.34 lbs), Canyon bike is considerably heavier than average. In short, the average Crosscountry bike weight is 10.97% lower than this one.
Overview of components
Fork
Canyon Grand Canyon 6 2023 bike is equipped with the Suntour XCR fork, and has 100mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
As for the wheels, Canyon Grand Canyon 6 2023, has a 27.5″ aluminum model. These wheels will provide you with more control over the bike. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Grand Canyon 6 comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
