Canyon Grand :ON 7 2023
2023 E-bike
Estimate price |
3,784$
Weight | 23.56 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Fork RockShox Judy Silver TK
-
Groupset Deore, FSA -
Suspension Hardtail -
Motor Bosch 250W 85Nm mid-drive -
Battery Bosch PowerTube 750Wh -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
169cm - 182cm
LG
180cm - 192cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Canyon Grand Canyon:ON AL, Axle dimension: 12x148 mm, Material: Aluminium (AL)
Suspension Fork
Rockshox Judy Silver 29 120mm Boost, Axle dimension: 15x110 mm, Stanchion Diameter: 30 mm, Travel: 120 mm, Fork steer tube diameter: 1 1/8" - 1,5", Offset: 51 mm, Weight: 2.30 kg
Drivetrain
Rear Derailleur
Shimano DEORE M6100, Cage length: long, Weight: 317 g
Shift Levers
Shimano Deore M6100 12s
Cassette
Shimano DEORE M6100, Number of sprockets: 12 | Shimano CS-M6100 Deore 12-speed Cassette 10-51
Crank
FSA 745 E-Bike Crank for Bosch Gen4
Bottom Bracket
Bosch, press-fit
Chain
Shimano CN-M6100 | Shimano SM-CN910 12-speed Quick-Link Chain Connector | Shimano CN-M6100 Deore 12-speed Chain 138 Links
Chain Guide
Canyon GP0432-01 Chain Guide
Wheels
Rims
RODI TRYP30 EVO, Rotor mount: Center Lock, Weight: 1.09 kg | RODI TRYP30 EVO, Rotor mount: Center Lock, Weight: 1.19 kg
Tires
Schwalbe Nobby Nic Performance, 2.6, Width: 2.6"
Brakes
Brakes
SRAM DB8
Cockpit
Stem
Canyon:ON ST0031, Canyon E-MTB stem., Length: 45 mm, Fork steer tube diameter: 1 1/8", Clamping diameter: 35,0 mm
Handlebar
Canyon:ON HB0056 Riser bar, Aluminum., Clamping diameter: 35,0 mm, Width: 760 mm, Rise: 20 mm
Grips
Canyon Lock-On Grips
Seat
Saddle
Fizik Terra Alpaca X5
Seatpost
Iridium, Clamp diameter: 30,9 mm, Material: Aluminium (AL), Weight: 280 g
Motor & Battery
Motor
Bosch Performance Line CX
Battery
Bosch PowerTube 750Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.53 mm | 1.47 mm | 1.43 mm | 1.38 mm |
| Bottom Bracket Height | 309 mm | 309 mm | 309 mm | 309 mm |
| Front Center | 723 mm | 753 mm | 783 mm | 814 mm |
| Rake | 55 mm | 55 mm | 55 mm | 56 mm |
| Trail | 92 mm | 92 mm | 92 mm | 91 mm |
| Stack | 642 mm | 656 mm | 670 mm | 683 mm |
| Reach | 420 mm | 445 mm | 470 mm | 495 mm |
| Top Tube Length | 593 mm | 622 mm | 651 mm | 680 mm |
| Seat Tube Angle | 76.5 ° | 76.5 ° | 76.5 ° | 76.5 ° |
| Seat Tube Length | 395 mm | 440 mm | 485 mm | 540 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 115 mm | 130 mm | 145 mm | 160 mm |
| Chainstay Length | 455 mm | 455 mm | 455 mm | 455 mm |
| Wheelbase | 1170 mm | 1201 mm | 1231 mm | 1262 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 777 mm | 787 mm | 818 mm | 832 mm |
| Front Travel | 120 mm | 120 mm | 120 mm | 120 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Max Height | 171 cm | 182 cm | 192 cm | cm |
About this model
Grand Canyon:ON 7 completes the Canyon E Grand Canyonon model. Canyon launched 17 e-bikes of this model so far. Take a sneak peek at all Canyon E Grand Canyonon e-bikes models from 2023, by clicking here.
Model range prices
The most economical model, the Canyon Grand Canyon:ON 7 2023 has a starting price of 3503$. Canyon Grand Canyon:ON 9 2023 on the other hand is the most expensive at 4565$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Trail e-bikes
If you want an acceptable Trail e-bike you should know that the average price is 3365$. However, this doesn’t mean that if you spend less money on a Trail e-bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
This e-bike was released in 2023 and its price was 3503$. Doing a quick comparison, we notice that Grand Canyon:ON 7 price is 4.1% higher than the average cost of a Trail e-bike.
Average weight for Trail e-bikes
If we make a quick analysis of the average weight of a Trail e-bike, we get 23.7 kg (52.25 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
Canyon Grand Canyon:ON 7 it’s weighing 23.56 kg (51.94 lbs). At this weight, is slightly lighter than average. In short, the average Trail e-bike weight is 0.59% higher than this one.
Grand Canyon:ON 7 components
Fork
Canyon Grand Canyon:ON 7 2023 e-bike is equipped with the RockShox Judy Silver TK fork, and has 120mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels size
The Grand Canyon:ON 7 2023 e-bike is equipped with 29″ aluminum wheels when leaving the factory. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, these wheels are not ideal for smaller people.
Brakes
Nothing is more important on a bike than its ability to brake properly. Canyon Grand Canyon:ON 7 is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
