Canyon Grizl CF SL 6 AXS 2023
2023 Road
Estimate price |
2,866$
Weight | 9.66 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Groupset Apex XPLR AXS -
Suspension Rigid -
Battery SRAM Powerpack -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
165cm - 173cm
SM
171cm - 179cm
MD
177cm - 185cm
LG
183cm - 190cm
XL
188cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Canyon Grizl CF SL, Light robust carbon frame with Gravel Pro geometry, 50 mm tyre clearance, and extended wheelbase for extra off-road stability., Axle dimension: 12x142 mm, Tyre Clearance: 50 mm, Material: Carbon (CF)
Suspension Fork
Canyon FK0124 CF Disc, Light, robust carbon fork with 3-screw mounting points on each side for attaching bottle cages and Anything Cages., Fork steer tube diameter: 1 1/4", Material: Carbon (CF)
Drivetrain
Rear Derailleur
SRAM Apex XPLR AXS
Shift Levers
SRAM Apex | SRAM Apex 12s
Cassette
SRAM XPLR 11-44 12s | SRAM PG 1231 12-speed Cassette 11-44
Crank
SRAM Apex Wide, Number of chainrings: 1
Bottom Bracket
SRAM Pressfit DUB Wide, Bottom bracket standard: PF 86,5, Weight: 65 g
Chain
SRAM Apex 12s | SRAM Apex 12-speed Chain 120L
Pedals
None included
Wheels
Rims
DT Swiss Gravel LN, Axle dimension: 12x100 mm, Rotor mount: Center Lock, Rim height: 25 mm, Weight: 946 g | DT Swiss Gravel LN, Axle dimension: 12x142 mm, Rotor mount: Center Lock, Rim height: 25 mm, Weight: 1.10 kg
Tires
Schwalbe G-One Bite Performance, 45mm, Width: 45mm | Schwalbe G-One R Super Race 28" x 45mm Gravel Tyre
Brakes
Brakes
Hydraulic Disc
Brake Levers
SRAM Apex | SRAM Apex 12s
Cockpit
Stem
Canyon ST0035, A lightweight and durable aluminium stem for use on gravel and road bikes., Fork steer tube diameter: 1 1/4", Clamping diameter: 31,8 mm
Handlebar
Canyon HB0064 Ergo, Robust aluminium handlebar with flared drops for enhanced off-road control., Clamping diameter: 31,8 mm, Width: 440 mm
Seat
Saddle
Selle Italia Model X, Gender: Unisex, Weight: 315 g
Seatpost
Canyon SP0057 VCLS, With vibration-absorbing design for top rear-end comfort., Setback: 20 mm, Clamp diameter: 27,2 mm, Material: Carbon (CF), Weight: 265 g
Motor & Battery
Battery
SRAM Powerpack
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.39 mm | 1.41 mm | 1.4 mm | 1.44 mm | 1.48 mm | 1.47 mm | 1.48 mm |
| Front Center | 594 mm | 594 mm | 612 mm | 613 mm | 626 mm | 648 mm | 662 mm |
| Rake | 43 mm | 43 mm | 42 mm | 43 mm | 43 mm | 43 mm | 43 mm |
| Trail | 74 mm | 68 mm | 76 mm | 67 mm | 65 mm | 63 mm | 63 mm |
| Stack | 520 mm | 535 mm | 554 mm | 577 mm | 603 mm | 624 mm | 642 mm |
| Reach | 375 mm | 380 mm | 395 mm | 400 mm | 407 mm | 425 mm | 434 mm |
| Top Tube Length | 520 mm | 529 mm | 550 mm | 562 mm | 576 mm | 600 mm | 615 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 432 mm | 462 mm | 492 mm | 522 mm | 552 mm | 582 mm | 612 mm |
| Head Tube Angle | 70 ° | 71 ° | 71 ° | 72.25 ° | 72.5 ° | 72.75 ° | 72.75 ° |
| Head Tube Length | 121 mm | 133 mm | 118 mm | 138 mm | 164 mm | 185 mm | 204 mm |
| Chainstay Length | 418 mm | 418 mm | 433 mm | 433 mm | 433 mm | 433 mm | 433 mm |
| Wheelbase | 1005 mm | 1005 mm | 1034 mm | 1035 mm | 1048 mm | 1070 mm | 1084 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 75 mm | 75 mm | 75 mm | 75 mm | 75 mm |
| Standover Height | 735 mm | 759 mm | 787 mm | 814 mm | 843 mm | 868 mm | 890 mm |
| Wheels | 650 | 650 | 700 | 700 | 700 | 700 | 700 |
| Rider Max Height | 167 cm | 173 cm | 179 cm | 185 cm | 190 cm | 195 cm | cm |
About this model
Grizl CF SL 6 AXS is a Canyon Grizl model. Canyon released 80 bikes variations of this model so far. You can easily view all of the Canyon Grizl bikes models from 2023, here.
Model range prices
Canyon Grizl 5 2023 is the most economical model, with a starting price of 1376$. Canyon Grizl CF SLX 8 Force AXS Trail 2023 on the other hand costs 5611$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Gravel bikes
According to our calculations, the average cost of a Gravel bike that is reliable is 2462$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Gravel bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 2646$. Comparing this to the average Gravel bike price, we see that the price is 7.47% higher.
Gravel bikes average weight
On a deeper look, we notice that the average weight of a Gravel bike is 8.13 kg (17.92 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
Canyon Grizl CF SL 6 AXS it’s weighing 9.66 kg (21.3 lbs). At this weight, is much heavier than average. To sum up, it’s 18.82% heavier than the average weight of Gravel bikes.
Grizl CF SL 6 AXS components
Fork material
Grizl CF SL 6 AXS has a carbon fork, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
When leaving the production line, the Grizl CF SL 6 AXS model has aluminum wheels. After 700c wheels, 650b is the second most popular choice for road bikes. However, if you want higher speeds, you should look for a bike with 700c wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Canyon Grizl CF SL 6 AXS is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
