Canyon Neuron:ON 8 WMN 2022
2022 E-bike
Estimate price |
4,587$
Weight | 24.45 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" / 29" -
Travel Front 120mm -
Travel Rear 130mm -
Fork RockShox 35 Silver
-
Groupset XT, Deore -
Suspension Full -
Motor Shimano 250W 85Nm mid-drive -
Battery Shimano BT-E8036 Akku 630WH -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
159cm - 173cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Canyon Neuron:ON, Aluminium frame, 130mm of rear suspension on Med-XL frames (125mm travel on XS-SM frames), award-winning Triple Phase Suspension design, internal battery, Boost 148 rear spacing, post-style brake mount (180)
Suspension Fork
RockShox 35 Silver, 130mm, 130mm of front suspension, 29er fork, Boost 110 spacing, 35mm steel stanchions, air spring, external rebound damping adjuster
Rear Shock
RockShox Deluxe Select R, 210x50, 130mm of rear suspension. The Deluxe Select delivers proven damping performance in a lightweight package, highly tunable DebonAir™ spring, adjustable rebound damping.
Drivetrain
Rear Derailleur
Shimano Deore XT, 12-speed, Precise 1x12 drivetrain.
Shift Levers
Shimano Deore, 12-speed, Rear derailleur shifter, 12-speed, 2-way release, I-Spec EV clamp allows 14mm lateral adjustment and 10-degrees rotation adjustment, 133 g
Cassette
Shimano Deore, 12-speed (10-51), Cassette packed with tricke-down performance features. Hyperglide+ tech provides fast, smooth shifting. Beam spider construction cuts weights and boosts stiffness. Gear range: 10-51.
Crank
Shimano STEPS e-MTB crank arms, Designed for the rigors of E-MTB riding, 24mm spindle, 170mm crank arms
Bottom Bracket
STEPS, press-fit
Chain
Shimano M6100 12-speed, HYPERGLIDE+ shift technology, quick link for easy connect and tool-free assembly
Wheels
Rims
Rodi TRYP 30 | Shimano MT400, Shimano MT400 front hub with Boost 110 spacing, Iridium 30 aluminum rim, 30mm inner rim width | Iridium 30 | Shimano MT410, Shimano MT410 rear hub with Boost 148 spacing, Iridium 30 aluminum rim, 30mm inner rim width
Tires
Schwalbe Nobby Nic SuperTrail Speedgrip, 29x2.6". Super Trail version, highly puncture-resistant with Apex sidewall protection, and bead-to-bead Snakeskin fabric layer, Tubeless Easy version | Schwalbe Hans Dampf SuperTrail, 2.6, 29x2.6". Super Trail version, highly puncture-resistant with Apex sidewall protection, and bead-to-bead Snakeskin fabric layer, Tubeless Easy version
Brakes
Brakes
Shimano Deore 2-piston, rear brake, 2-piston disc brake, compatible with ICE TECH brake pads | Shimano Deore 4-piston, front brake, High-power 4-piston Deore brake, quick pad retraction, compatible with ICE TECH brake pads
Disk Rotors
Shimano Tourney TX front rotor, A big Shimano RT830 brake rotor delivers equally big stopping power. | Shimano EM300 STEPS rear rotor, 203mm, Specifically designed to work with E-MTB speed sensors. Center lock mounting for quick installation/removal. Resin pad only.
Cockpit
Stem
Canyon:ON Stem, 35mm clamp diameter, 60mm length
Handlebar
Canyon:ON HB0056 Riser bar, Aluminum, 760mm width, 35mm clamp diameter, 20mm rise
Grips
Canyon Lock-On Grips
Seat
Saddle
Canyon SD:ON, Perfect for long rides in a seated position or on steep climbs, extra padding around sit bones, additional rear support prevents you from sliding backwards on steep climbs, chromoly rails, durable nylon composite shell, 290 g
Seatpost
Iridium Dropper Post, Iridium dropper posts provide seat-height adjustability, varying depending on frame size. Internally routed, cable actuated, 30.9mm diameter.
Motor & Battery
Motor
Shimano Steps EP8 Motor
Battery
Shimano BT-E8036 Akku 630WH
Remote
Shimano Steps SC-E7000 Display
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD |
|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.43 mm | 1.44 mm |
| Bottom Bracket Height | 335 mm | 335 mm | 341 mm |
| Front Center | 694 mm | 714 mm | 736 mm |
| Rake | 40 mm | 30 mm | 51 mm |
| Trail | 111 mm | 122 mm | 100 mm |
| Stack | 581 mm | 604 mm | 622 mm |
| Reach | 402 mm | 422 mm | 432 mm |
| Top Tube Length | 548 mm | 556 mm | 593 mm |
| Seat Tube Angle | 75 ° | 75 ° | 74.5 ° |
| Seat Tube Length | 380 mm | 420 mm | 440 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 67.5 ° |
| Head Tube Length | 100 mm | 100 mm | 120 mm |
| Chainstay Length | 432 mm | 432 mm | 437 mm |
| Wheelbase | 1125 mm | 1145 mm | 1171 mm |
| Bottom Bracket Drop | 20 mm | 20 mm | 33 mm |
| Standover Height | 763 mm | 769 mm | 795 mm |
| Front Travel | 120 mm | 120 mm | 130 mm |
| Rear Travel | 130 mm | 130 mm | 130 mm |
| Wheels | 27" | 27" | 29" |
| Rider Max Height | 161 cm | 173 cm | cm |
Model Overview
Neuron:ON 8 WMN is part of the Canyon E Neuronon model. Canyon launched 27 e-bikes of this model so far. Check out the entire range from 2022 of this model, by clicking this link.
Model range prices
The most economical model, the Canyon Neuron:ON 7 WMN 2022 has a starting price of 3928$. Canyon Neuron:ON 9 2022 on the other hand is the most expensive at 4671$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Trail e-bikes average price
According to our math, the average price for a trustworthy Trail e-bike is 3365$. However, this doesn’t mean that if you spend less money on a Trail e-bike, you couldn’t get a decent one. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 4246$. In conclusion, this e-bike price is 26.18% more expensive than the price of the average Trail e-bike.
Trail e-bikes average weight
On a deeper look, we notice that the average weight of a Trail e-bike is 23.7 kg (52.25 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
slightly heavier than average, Neuron:ON 8 WMN has a weight of 24.45 kg (53.9 lbs). In conclusion, the average Trail e-bike weighs 3.16% less than Neuron:ON 8 WMN.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Neuron:ON 8 WMN components
Fork
This e-bike has the RockShox 35 Silver fork installed. The fork’s travel is 120mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Fork material
The fork on this e-bike is made out of steel, which tends to be more flexible than carbon forks in general. However, a carbon fork is considerably lighter.
Rear Shock
The Neuron:ON 8 WMN has a rear shock with a travel of 130mm. The model RockShox Deluxe Select R is the one installed in this e-bike. Rear shocks improve riding comfort and give you greater control over all terrains. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels
The wheels on Neuron:ON 8 WMN are the 27.5″ aluminum type. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Neuron:ON 8 WMN comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Dropper post
A dropper post is included with the Neuron:ON 8 WMN. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
