Canyon Pathlite WMN AL SL 8.0 2020
2020 Urban
Estimate price |
1,949$
Weight | 11.6 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 650b / 29" -
Travel Front 75mm -
Fork SunTour NRX E
-
Groupset XT -
Suspension Hardtail -
Drivetrain 2 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
155cm - 163cm
SM
161cm - 173cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Canyon Pathlite WMN AL SL
Suspension Fork
SR Suntour NRX-E Air, Travel: 75 mm, Axle Dimension: 15 x 100 mm
Drivetrain
Rear Derailleur
Shimano XT M8100 SGS
Front Derailleur
Shimano XT M8100
Shift Levers
Shimano XT M8100 | Shimano Deore XT M8100 12s, Clamp: I-Spec EV
Cassette
Shimano SLX M710012 10-45 12s
Crank
Shimano XT M8100 36/26 36/26
Bottom Bracket
Shimano Pressfit BB-MT500
Chain
Shimano CN-M7100 12s
Wheels
Rims
Alexrims GX26P / Shimano MT400 | Alexrims GX26P / Shimano MT510 S12
Tires
Schwalbe G-One Bite 40 mm
Brakes
Brakes
Shimano XT M8100
Disk Rotors
Shimano RT54
Cockpit
Grips
VELO VLG-1777D2
Seat
Saddle
Iridium Fitness
Seatpost
Canyon SP0041 VCLS CF, Material: Carbon, Setback: 20 mm, Technology: VCLS
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD |
|---|---|---|---|---|
| Stack Reach Ratio | 1.61 mm | 1.56 mm | 1.56 mm | 1.59 mm |
| Front Center | 602 mm | 619 mm | 623 mm | 637 mm |
| Rake | 46 mm | 46 mm | 46 mm | 45 mm |
| Trail | 71 mm | 71 mm | 72 mm | 73 mm |
| Stack | 584 mm | 589 mm | 609 mm | 633 mm |
| Reach | 363 mm | 378 mm | 391 mm | 397 mm |
| Top Tube Length | 537 mm | 554 mm | 572 mm | 585 mm |
| Seat Tube Angle | 73.25 ° | 73.25 ° | 73.25 ° | 73.25 ° |
| Seat Tube Length | 355 mm | 385 mm | 425 mm | 455 mm |
| Head Tube Angle | 70 ° | 70 ° | 71 ° | 71 ° |
| Head Tube Length | 91 mm | 96 mm | 94 mm | 119 mm |
| Chainstay Length | 426 mm | 426 mm | 431 mm | 431 mm |
| Wheelbase | 1024 mm | 1041 mm | 1046 mm | 1060 mm |
| Bottom Bracket Drop | 44 mm | 44 mm | 62 mm | 62 mm |
| Standover Height | 703 mm | 724 mm | 757 mm | 785 mm |
| Front Travel | 75 mm | 75 mm | 75 mm | 75 mm |
| Wheels | 650 | 650 | 29" | 29" |
| Rider Max Height | 157 cm | 163 cm | 173 cm | cm |
About this model
Pathlite WMN AL SL 8.0 is a Canyon Pathlite model. Canyon released 41 bikes variations of this model so far. You can get a glimpse at all models from 2020, by clicking on this link.
Model range prices
Canyon Pathlite AL 4.0 2020 is the most affordable bike of this model and has a price of 955$. On the other hand, Canyon Pathlite AL SL 8.0 2020, is the most expensive and costs 1804$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Fitness bikes
If you want to purchase a solid Fitness bike, it is important to know that the average cost is 656$. However, even if your budget is less than the average, you might still be able to get a top-quality Fitness bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
This bike was released in 2020 and its price was 1804$. Comparing this to the average Fitness bike price, we see that the price is 175% more expensive.
Fitness bikes average weight
Fitness bikes weigh an average of 11.24 kg (24.78 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
Canyon Pathlite WMN AL SL 8.0 it’s weighing 11.6 kg (25.57 lbs). At this weight, is slightly heavier than average. In other words, this model is 3.2% heavier than the average Fitness bike.
Overview of components
Fork
The fork installed on this bike is the SunTour NRX E model. The travel on this model is 75mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
The Pathlite WMN AL SL 8.0 2020 bike is equipped with aluminum wheels when leaving the factory. The 650b wheels are very similar to 700c, with a slight difference in diameter. However, if speed is what you’re after, 700c wheels are a better fit.
Brakes
Nothing is more important on a bike than its ability to brake properly. Canyon Pathlite WMN AL SL 8.0 is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
