Canyon Pathlite:ON 5 2022
2022 E-bike
Estimate price |
3,096$
Weight | 23.5 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 650b / 29" -
Travel Front 100mm -
Fork SunTour XCM
-
Groupset Deore, FSA -
Suspension Hardtail -
Motor Bosch 250W 85Nm mid-drive -
Battery Bosch PowerTube 500 Wh -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
165cm - 175cm
MD
173cm - 185cm
LG
183cm - 193cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Canyon Pathlite:ON
Suspension Fork
Suntour XCM34, 100mm
Drivetrain
Rear Derailleur
Shimano Deore M5100 11s
Shift Levers
Shimano Deore M5100
Cassette
Shimano Deore M5100 11s 11-51
Crank
FSA CK-220 GEN4 ISIS
Chain
Shimano CN-HG601 11s, Chain featuring SIL-TEC ultra-low friction surface treatment for precise shifting and improved durability.
Wheels
Rims
Alexrims MD25 | Kun Teng XC8F | Alexrims MD25 | Kun Teng 2H3MR
Tires
Schwalbe G-One Allround 57mm
Brakes
Brakes
Shimano MT200
Disk Rotors
Shimano RT30 | Shimano EM300, Disc Mount: Centerlock
Cockpit
Stem
Iridium
Handlebar
Iridium Flatbar, Material: Aluminium, Rise: 5 mm
Grips
Ergon GA3, Premium grips with miniwing design for extra hand support.
Seat
Saddle
Fizik Essenza
Seatpost
LightSKIN seat post with integrated LED rear light
Motor & Battery
Motor
Bosch Performance Line CX (Gen4)
Battery
Bosch PowerTube 500 Wh
Remote
Bosch Purion
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.65 mm | 1.63 mm | 1.63 mm | 1.6 mm | 1.61 mm |
| Front Center | 623 mm | 631 mm | 646 mm | 673 mm | 714 mm |
| Rake | 44 mm | 44 mm | 51 mm | 51 mm | 50 mm |
| Trail | 76 mm | 76 mm | 71 mm | 71 mm | 73 mm |
| Stack | 616 mm | 621 mm | 636 mm | 657 mm | 703 mm |
| Reach | 374 mm | 380 mm | 391 mm | 410 mm | 436 mm |
| Top Tube Length | 555 mm | 562 mm | 581 mm | 606 mm | 646 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.23 ° | 73.23 ° | 73.24 ° |
| Seat Tube Length | 440 mm | 465 mm | 490 mm | 520 mm | 550 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 70.2 ° | 70.2 ° | 70.2 ° |
| Head Tube Length | 92 mm | 98 mm | 92 mm | 114 mm | 163 mm |
| Chainstay Length | 449 mm | 449 mm | 466 mm | 466 mm | 466 mm |
| Wheelbase | 1064 mm | 1072 mm | 1104 mm | 1131 mm | 1173 mm |
| Bottom Bracket Drop | 63 mm | 63 mm | 64 mm | 64 mm | 64 mm |
| Standover Height | 753 mm | 798 mm | 834 mm | 856 mm | 891 mm |
| Front Travel | 100 mm | 100 mm | 100 mm | 100 mm | 100 mm |
| Wheels | 650 | 650 | 29" | 29" | 29" |
| Rider Max Height | 167 cm | 175 cm | 185 cm | 193 cm | cm |
About this model
Pathlite:ON 5 belongs to the Canyon E Pathliteon model. Canyon launched 44 e-bikes of this model so far. You can get a glimpse at all models from 2022, by clicking on this link.
Model range prices
Canyon Pathlite:ON 4 2022 is the cheapest e-bike model and costs 2653$. Canyon Pathlite:ON 9.0 2022 is the most expensive one and costs 5308$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Fitness e-bikes
Our math shows that the average cost of a dependable Fitness e-bike is 2351$. However, you could also get a good Fitness e-bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
This e-bike was released in 2022 and its price was 2866$. Comparing this to the average Fitness e-bike price, we see that the price is 21.91% higher.
Fitness e-bikes average weight
On a deeper look, we notice that the average weight of a Fitness e-bike is 22.85 kg (50.38 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
Pathlite:ON 5 weighs 23.5 kg (51.81 lbs) and is slightly heavier than the average. To sum up, it’s 2.84% heavier than the average weight of Fitness e-bikes.
Overview of components
Fork
The Pathlite:ON 5 comes factory-installed with the SunTour XCM fork. This has a travel range of 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels size
When it comes to wheels, the Pathlite:ON 5 e-bike is equipped with the aluminum model. After 700c wheels, 650b is the second most popular choice for road bikes. However, if you want higher speeds, you should look for a bike with 700c wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Pathlite:ON 5 comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
