Canyon Pathlite:ON 5 2023
2023 E-bike
Estimate price |
3,096$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 100mm -
Fork Suntour XCM
-
Groupset Deore, FSA -
Suspension Hardtail -
Motor Bosch 250W 85Nm mid-drive -
Battery Bosch PowerTube -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
165cm - 175cm
MD
173cm - 185cm
LG
183cm - 193cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Canyon Pathlite:ON, Axle dimension: 12x148 mm, Material: Aluminium (AL)
Suspension Fork
Suntour XCM34, 100mm, Travel: 100 mm
Drivetrain
Rear Derailleur
Shimano Deore M5100 11s, Cage length: long
Shift Levers
Shimano Deore M5100 11s
Cassette
SunRace CSMS8 11s 11-51T, Number of sprockets: 11
Crank
FSA CK-220 GEN4 ISIS
Chain
Shimano CN-HG601 11s, Chain featuring SIL-TEC ultra-low friction surface treatment for precise shifting and improved durability.
Wheels
Rims
Alexrims MD25 | Shimano MT400, Rotor mount: Center Lock, Wheelsize: 29" | Alexrims MD25 | Shimano MT400 SH11, Rotor mount: Center Lock, Wheelsize: 29"
Tires
Schwalbe G-One Allround 57mm, Width: 2.25"
Brakes
Brakes
Shimano MT200
Cockpit
Stem
Iridium, Iridium, Fork steer tube diameter: 1 1/8"
Handlebar
Iridium Flatbar, Material: Aluminium, Rise: 5 mm
Grips
Ergon GA3, Premium grips design for extra hand support.
Seat
Saddle
Selle Royal Essenza plus athletic
Seatpost
LightSKIN seat post with integrated LED rear light, Clamp diameter: 30,9 mm, Material: Aluminium (AL)
Motor & Battery
Motor
Bosch Performance Line CX
Battery
Bosch PowerTube
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.65 mm | 1.63 mm | 1.63 mm | 1.6 mm | 1.61 mm |
| Front Center | 623 mm | 631 mm | 646 mm | 673 mm | 714 mm |
| Rake | 44 mm | 44 mm | 51 mm | 51 mm | 50 mm |
| Trail | 76 mm | 76 mm | 71 mm | 71 mm | 73 mm |
| Stack | 616 mm | 621 mm | 636 mm | 657 mm | 703 mm |
| Reach | 374 mm | 380 mm | 391 mm | 410 mm | 436 mm |
| Top Tube Length | 555 mm | 562 mm | 581 mm | 606 mm | 646 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.23 ° | 73.23 ° | 73.24 ° |
| Seat Tube Length | 440 mm | 465 mm | 490 mm | 520 mm | 550 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 70.2 ° | 70.2 ° | 70.2 ° |
| Head Tube Length | 92 mm | 98 mm | 92 mm | 114 mm | 163 mm |
| Chainstay Length | 449 mm | 449 mm | 466 mm | 466 mm | 466 mm |
| Wheelbase | 1064 mm | 1072 mm | 1104 mm | 1131 mm | 1173 mm |
| Bottom Bracket Drop | 63 mm | 63 mm | 64 mm | 64 mm | 64 mm |
| Standover Height | 753 mm | 798 mm | 834 mm | 856 mm | 891 mm |
| Front Travel | 100 mm | 100 mm | 100 mm | 100 mm | 100 mm |
| Wheels | 27" | 27" | 29" | 29" | 29" |
| Rider Max Height | 167 cm | 175 cm | 185 cm | 193 cm | cm |
Model Overview
Pathlite:ON 5 is a Canyon E Pathliteon model. Canyon launched 44 e-bikes of this model so far. Take a sneak peek at all Canyon E Pathliteon e-bikes models from 2023, by clicking here.
Model range prices
Canyon Pathlite:ON 4 2023 is the cheapest e-bike model and costs 2653$. Canyon Pathlite:ON 9 LTD SUV 2023 is the most expensive one and costs 5839$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Fitness e-bikes average price
According to our calculations, the average cost of a Fitness e-bike that is reliable is 2351$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Fitness e-bike. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
This e-bike was released in 2023 and its price was 2866$. If we compare this with the average Fitness e-bike cost we notice that the price is 21.91% higher.
Overview of components
Fork
The Pathlite:ON 5 comes factory-installed with the Suntour XCM fork. This has a travel range of 100mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels size
When leaving the production line, the Pathlite:ON 5 model has 27.5″ aluminum wheels. These wheels will provide you with more control over the e-bike. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The Pathlite:ON 5 has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
