Canyon Pathlite:ON 8 2021
2021 E-bike
Estimate price |
4,587$
Weight | 27.57 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 650b / 29" -
Travel Front 100mm -
Fork SunTour XCR 34
-
Groupset XT, Deore -
Suspension Hardtail -
Motor Bosch 250W 85Nm mid-drive -
Battery Bosch PowerTube 500 Wh | Bosch PowerPack 500 Wh -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
173cm - 185cm
LG
183cm - 193cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Canyon Pathlite:ON, Material: Aluminium, Axle Dimension: 12 x 148 mm, Brake Mount: Post Mount 180, Interface: 40 mm Kickstand Mount
Suspension Fork
SR Suntour XCR34 Air
Drivetrain
Rear Derailleur
Shimano Deore XT, 12-speed, Precise 1x12 drivetrain.
Shift Levers
Shimano Deore, 12-speed, Rear derailleur shifter, 12-speed, 2-way release, I-Spec EV clamp allows 14mm lateral adjustment and 10-degrees rotation adjustment, 133 g
Cassette
Shimano Deore, 12-speed (10-51), Cassette packed with tricke-down performance features. Hyperglide+ tech provides fast, smooth shifting. Beam spider construction cuts weights and boosts stiffness. Gear range: 10-51.
Crank
FSA CK-220 GEN4 ISIS
Chain
Shimano CN-M6100 12s
Wheels
Rims
Alexrims MD25 | Shimano MT400 | Alexrims MD25 | Shimano MT410-B
Tires
Schwalbe G-One Allround 57 mm
Brakes
Brakes
Shimano MT420 | Shimano Deore MT4100
Disk Rotors
Shimano EM300, Disc Mount: Centerlock | Shimano RT54
Cockpit
Grips
Ergon GS2
Seat
Saddle
Fizik Essenza
Seatpost
Iridium
Motor & Battery
Motor
Bosch Performance Line CX (Gen4)
Battery
Bosch PowerTube 500 Wh | Bosch PowerPack 500 Wh
Remote
Bosch Purion
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.65 mm | 1.64 mm | 1.62 mm | 1.63 mm |
| Front Center | 631 mm | 646 mm | 673 mm | 714 mm |
| Rake | 44 mm | 51 mm | 51 mm | 50 mm |
| Trail | 76 mm | 71 mm | 71 mm | 73 mm |
| Stack | 612 mm | 627 mm | 648 mm | 694 mm |
| Reach | 371 mm | 382 mm | 401 mm | 427 mm |
| Top Tube Length | 553 mm | 572 mm | 597 mm | 637 mm |
| Seat Tube Angle | 73.5 ° | 73.2 ° | 73.2 ° | 73.2 ° |
| Seat Tube Length | 465 mm | 490 mm | 520 mm | 550 mm |
| Head Tube Angle | 69.5 ° | 70.2 ° | 70.2 ° | 70.2 ° |
| Head Tube Length | 98 mm | 92 mm | 114 mm | 163 mm |
| Chainstay Length | 440 mm | 457 mm | 457 mm | 457 mm |
| Wheelbase | 1063 mm | 1095 mm | 1122 mm | 1164 mm |
| Bottom Bracket Drop | 63 mm | 64 mm | 64 mm | 64 mm |
| Standover Height | 789 mm | 825 mm | 847 mm | 882 mm |
| Front Travel | 100 mm | 100 mm | 100 mm | 100 mm |
| Wheels | 650 | 29" | 29" | 29" |
| Rider Max Height | 175 cm | 185 cm | 193 cm | cm |
About this model
Pathlite:ON 8 is part of the Canyon E Pathliteon model. 44 e-bikes variations carry this model name so far. You can get a glimpse at all models from 2021, by clicking on this link.
Model range prices
Canyon Pathlite:ON 6 2021 is the most economical model, with a starting price of 3004$. Canyon Pathlite:ON 9.0 2021 on the other hand costs 5308$, and is the most expensive model.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Fitness e-bikes
According to our math, the average price for a trustworthy Fitness e-bike is 2351$. However, even though the average price of a Fitness e-bike is lower, you might still be able to get a top-quality e-bike. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2021 for 4246$. If we compare this with the average Fitness e-bike cost we notice that the price is 80.6% higher.
Average weight for Fitness e-bikes
The average weight for Fitness e-bikes is 22.85 kg (50.38 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
Canyon Pathlite:ON 8 it’s weighing 27.57 kg (60.78 lbs). At this weight, is much heavier than average. In conclusion, the average Fitness e-bike weighs 20.66% less than Pathlite:ON 8.
Overview of components
Fork
This e-bike has the SunTour XCR 34 fork installed. The fork’s travel is 100mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
When leaving the production line, the Pathlite:ON 8 model has aluminum wheels. 650b wheels make a great choice if you want to sacrifice speed for comfort. However, if speed is what you’re after, 700c wheels are a better fit.
Brakes
For your safety, it is important to have quality breaks on your bike. Canyon Pathlite:ON 8 has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
