Canyon Spectral 27.5 CF 7 2023
2023 Mountain
Estimate price |
3,399$
Weight | 14.4 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 160mm -
Travel Rear 150mm -
Fork Fox Rhythm Float 36
-
Groupset SLX -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
165cm - 176cm
MD
174cm - 184cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Canyon Spectral CF, Full-carbon frame with optimised stiffness-to-weight ratio. With Flip Chip system for simple geometry adjustment. Category 4., Axle dimension: 12x148 mm, Material: Carbon (CF)
Suspension Fork
FOX 36 Rhythm Grip, Axle dimension: 15x110 mm, Stanchion Diameter: 36 mm, Travel: 160 mm, Fork steer tube diameter: 1 1/8" - 1,5", Offset: 37 mm, Weight: 1.97 kg
Rear Shock
FOX Float X Performance
Drivetrain
Rear Derailleur
Shimano SLX M7100, Cage length: long, Weight: 286 g
Shift Levers
Shimano SLX M7100
Cassette
Shimano SLX M7100, Number of sprockets: 12
Crank
Shimano SLX M7120, Number of chainrings: 1
Bottom Bracket
Token BSA, Bottom bracket standard: BSA 68/73, Weight: 98 g
Chain
Shimano M6100, SIL-TEC treatment for extended offroad durability, HYPERGLIDE+ shift technology, quick link for easy connect and tool-free assembly
Chain Guide
Canyon EP1266-01 ISCG05 Plate | Canyon GP0293-02
Pedals
None included
Wheels
Rims
DT SWISS XM1900, Axle dimension: 15x110 mm, Rotor mount: IS 6-bolt, Weight: 882 g | DT SWISS XM1900, Rotor mount: IS 6-bolt, Weight: 1.02 kg
Tires
MAXXIS Minion DHR II 2.4'', Width: 2.4", Weight: 900 g | Maxxis Minion DHR II 3C MaxxTerra EXO+ 2,4x27,5", Wheelsize: 27.5", Weight: 1.07 kg
Brakes
Brakes
Shimano SLX M7120
Cockpit
Stem
Canyon G5, Modern design, extreme durability: Canyon G5 components were developed by our pros on the world's toughest trails., Fork steer tube diameter: 1 1/8", Clamping diameter: 31,8 mm
Handlebar
Canyon G5, G5 stands for gravity riding, and category 5. This aluminium bar has superb ergonomics and durability., Clamping diameter: 31,8 mm, Width: 780 mm, Rise: 30 mm
Grips
Canyon G5
Seat
Saddle
Ergon SM10 Enduro Comp
Seatpost
Canyon G5, Clamp diameter: 30,9 mm, Material: Aluminium (AL)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.42 mm | 1.36 mm | 1.31 mm |
| Bottom Bracket Height | 335 mm | 335 mm | 335 mm | 335 mm |
| Front Center | 732 mm | 766 mm | 795 mm | 824 mm |
| Rake | 42 mm | 43 mm | 42 mm | 42 mm |
| Trail | 123 mm | 122 mm | 123 mm | 123 mm |
| Stack | 591 mm | 609 mm | 618 mm | 627 mm |
| Reach | 405 mm | 430 mm | 455 mm | 480 mm |
| Top Tube Length | 548 mm | 577 mm | 605 mm | 632 mm |
| Seat Tube Angle | 76.5 ° | 76.5 ° | 76.5 ° | 76.5 ° |
| Seat Tube Length | 395 mm | 395 mm | 430 mm | 460 mm |
| Head Tube Angle | 64.5 ° | 64.5 ° | 64.5 ° | 64.5 ° |
| Head Tube Length | 105 mm | 125 mm | 135 mm | 145 mm |
| Chainstay Length | 427 mm | 427 mm | 427 mm | 427 mm |
| Wheelbase | 1158 mm | 1192 mm | 1221 mm | 1250 mm |
| Bottom Bracket Drop | 20 mm | 20 mm | 20 mm | 20 mm |
| Standover Height | 741 mm | 746 mm | 753 mm | 756 mm |
| Front Travel | 160 mm | 160 mm | 160 mm | 160 mm |
| Rear Travel | 150 mm | 150 mm | 150 mm | 150 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Max Height | 167 cm | 176 cm | 184 cm | cm |
About this model
Spectral 27.5 CF 7 completes the Canyon Spectral model. 97 bikes variations carry this model name so far. You can easily view all of the Canyon Spectral bikes models from 2023, here.
Model range prices
Canyon Spectral 4 2023 is the most economical model, with a starting price of 2299$. Canyon Spectral 29 CFR 2023 on the other hand costs 6499$, and is the most expensive model.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Enduro bikes average price
According to our math, the average price for a trustworthy Enduro bike is 3599$. However, even if your budget is less than the average, you might still be able to get a top-quality Enduro bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 3399$. Comparing the average cost of an Enduro bike to this one, you will see that Spectral 27.5 CF 7 price is 5.88% lower.
Average weight for Enduro bikes
If we make a quick analysis of the average weight of an Enduro bike, we get 14.27 kg (31.46 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
With a weight of 14.4 kg (31.75 lbs), Canyon bike is slightly heavier than average. In other words, this model is 0.91% heavier than the average Enduro bike.
Overview of components
Fork
This bike has the Fox Rhythm Float 36 fork installed. The fork’s travel is 160mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
As for the rear shock, this bike has the FOX Float X Performance model, with a travel of 150mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
When leaving the production line, the Spectral 27.5 CF 7 model has 27.5″ aluminum wheels. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The Spectral 27.5 CF 7 has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Dropper post
The Canyon model is also equipped with a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
