Canyon Spectral:ON WMN 7.0 2019
2019 E-bike
Estimate price |
4,701$
Weight | 22 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 150mm -
Travel Rear 150mm -
Fork Fox Performance Elite Float 36
-
Groupset XT, Shimano -
Suspension Full -
Motor Shimano 250W 70Nm mid-drive -
Battery Shimano Steps E8010 504 Wh -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
165cm - 175cm
MD
173cm - 183cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Canyon Spectral:On, Material: Aluminium 6061, Travel: 150 mm, Axle Dimension: 12 x 148 mm, Brake Mount: Post Mount 180
Suspension Fork
FOX 36 Performance Elite, Travel: 150 mm, Technology: FIT4, Axle Dimension: 15 x 110 mm
Rear Shock
FOX FLOAT DPS Performance, Length: 230 x 60 mm
Drivetrain
Rear Derailleur
Shimano Deore XT M8000 GS
Shift Levers
Shimano Deore XT M8000 11s, Clamp: I-Spec II
Cassette
Shimano SLX M7000 11-46 11s
Crank
Shimano E8000
Chain
Shimano CN-HG601 11s
Wheels
Rims
DT Swiss H 1900 SH11, Rim Material: Aluminium, Inner Width: 35 mm, Freewheel: 3 Pawl, Weight: 1194 g
Tires
MAXXIS Minion DHR II 2.8'', Casing: Exo, Compound: 3C Triple, Technology: Tubeless ready
Brakes
Brakes
Shimano Deore XT M8020, Technology: Ice Tech
Disk Rotors
Shimano RT86, Disc Mount: 6-Hole
Cockpit
Stem
Race Face Aeffect R
Handlebar
Race Face Aeffect Riserbar, Material: Aluminium, Rise: 20 mm
Grips
Canyon Lock-On
Seat
Saddle
Canyon SD:ON
Seatpost
Iridium Dropper
Motor & Battery
Motor
Shimano Steps E8000
Battery
Shimano Steps E8010 504 Wh
Remote
Shimano Steps E7000
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD |
|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.45 mm | 1.4 mm |
| Bottom Bracket Height | 335 mm | 322 mm | 322 mm |
| Front Center | 722 mm | 733 mm | 755 mm |
| Rake | 51 mm | 52 mm | 52 mm |
| Trail | 102 mm | 96 mm | 96 mm |
| Stack | 608 mm | 621 mm | 625 mm |
| Reach | 408 mm | 428 mm | 448 mm |
| Top Tube Length | 585 mm | 600 mm | 619 mm |
| Seat Tube Angle | 73.3 ° | 73.8 ° | 73.8 ° |
| Seat Tube Length | 420 mm | 430 mm | 440 mm |
| Head Tube Angle | 66 ° | 66.8 ° | 66.8 ° |
| Head Tube Length | 100 mm | 95 mm | 100 mm |
| Chainstay Length | 433 mm | 433 mm | 433 mm |
| Wheelbase | 1154 mm | 1164 mm | 1186 mm |
| Bottom Bracket Drop | 20 mm | 33 mm | 33 mm |
| Standover Height | 774 mm | 781 mm | 783 mm |
| Front Travel | 150 mm | 150 mm | 150 mm |
| Rear Travel | 150 mm | 150 mm | 150 mm |
| Wheels | 27" | 27" | 27" |
| Rider Max Height | 167 cm | 175 cm | 183 cm |
Model Overview
Spectral:ON WMN 7.0 belongs to the Canyon E Spectralon model. 37 e-bikes variations carry this model name so far. You can get a glimpse at all models from 2019, by clicking on this link.
Model range prices
Canyon Spectral:ON WMN 6.0 2019 is the cheapest e-bike model and costs 3609$. Canyon Spectral:ON 9.0 2019 is the most expensive one and costs 5945$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Enduro e-bikes average price
According to our calculations, the average cost of an Enduro e-bike that is reliable is 4785$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Enduro e-bike. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 4352$. If we compare this with the average Enduro e-bike cost we notice that the price is 9.95% lower.
Enduro e-bikes average weight
Enduro e-bikes have an average weight of 23.42 kg (51.63 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
a bit lighter than average, Spectral:ON WMN 7.0 has a weight of 22 kg (48.5 lbs). To sum up, it’s 6.45% lighter than the average weight of Enduro e-bikes.
Spectral:ON WMN 7.0 components
Fork
Canyon Spectral:ON WMN 7.0 2019 e-bike is equipped with the Fox Performance Elite Float 36 fork, and has 150mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
From the factory, it comes with the FOX FLOAT DPS Performance rear shock model, which has a travel of 150mm. Rear shocks improve riding comfort and give you greater control over all terrains. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels
The wheels on Spectral:ON WMN 7.0 are the 27.5″ aluminum type. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Canyon Spectral:ON WMN 7.0 has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Dropper post
The Canyon model is also equipped with a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
