Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra Di2 -
Suspension Rigid -
Drivetrain 2 × 11 Electronic -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon fiber
Suspension Fork
Cerv?©lo All-Carbon, Tapered S3 Fork
Drivetrain
Rear Derailleur
Shimano Ultegra Di2 8050, 11spd
Front Derailleur
Shimano Ultegra Di2 8050, 11 speed
Shift Levers
Shimano Ultegra Di2 8050, 11spd
Cassette
Shimano Ultegra CS-R8000, 11-30
Crank
Shimano Ultegra 8000 52/36
Bottom Bracket
Cervelo BBright Connect 24x90
Chain
Shimano CN-HG701, 11 speed
Wheels
Rims
Novatec R5 Carbon 50mm
Tires
Continental Grand Prix SL 25mm
Brakes
Brakes
Shimano Ultegra 8000
Cockpit
Stem
Cervelo ST29
Handlebar
Cervelo AB09
Headset
FSA IS2 1-1/4 x 1-3/8”
Seat
Saddle
Prologo Dimension STN
Seatpost
Cervelo SP20
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 51cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.44 mm | 1.47 mm | 1.51 mm | 1.53 mm | 1.56 mm |
| Bottom Bracket Height | 263 mm | 263 mm | 266 mm | 266 mm | 268 mm | 268 mm |
| Front Center | 574.9 mm | 576.9 mm | 578.6 mm | 586.1 mm | 603.9 mm | 620.2 mm |
| Rake | 58 mm | 52 mm | 46 mm | 43 mm | 43 mm | 43 mm |
| Trail | 57.1 mm | 57.1 mm | 57.1 mm | 57.1 mm | 57.1 mm | 57.1 mm |
| Stack | 500 mm | 525 mm | 550 mm | 575 mm | 600 mm | 625 mm |
| Reach | 355 mm | 364 mm | 373 mm | 381 mm | 391 mm | 400 mm |
| Top Tube Length | 510 mm | 527 mm | 543 mm | 558 mm | 576 mm | 592 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 480 mm | 510 mm | 540 mm | 560 mm | 580 mm | 610 mm |
| Head Tube Angle | 71 ° | 72 ° | 73 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Head Tube Length | 103.4 mm | 123.9 mm | 147.2 mm | 170.6 mm | 199.3 mm | 225.4 mm |
| Chainstay Length | 400 mm | 400 mm | 400 mm | 400 mm | 400 mm | 400 mm |
| Wheelbase | 963 mm | 965 mm | 968 mm | 975 mm | 994 mm | 1010 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 70 mm | 70 mm | 67 mm | 67 mm |
| Standover Height | 708 mm | 737 mm | 766 mm | 796 mm | 819 mm | 843 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
S3 Ultegra Di2 Rim completes the Cervelo S3 model. Cervélo released 13 bikes variations of this model so far. You can get a glimpse at all models from 2019, by clicking on this link.
Model range prices
Cervélo S3 Ultegra Rim 2019 is the cheapest bike model and costs 5000$. Cervélo S3 Ultegra Di2 Disc 2019 is the most expensive one and costs 6500$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Aero bikes
According to our math, the average price for a trustworthy Aero bike is 4211$. However, even if your budget is less than the average, you might still be able to get a top-quality Aero bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2019 for 6500$. Comparing the average cost of an Aero bike to this one, you will see that S3 Ultegra Di2 Rim price is 54.36% higher.
S3 Ultegra Di2 Rim components
Fork material
The fork is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
When leaving the production line, the S3 Ultegra Di2 Rim model has 700c carbon wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, they have problems in wet conditions.
