Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Force eTap -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon fiber
Suspension Fork
Cervélo All-Carbon, Tapered S5 Fork
Drivetrain
Rear Derailleur
SRAM Force AXS, 12 speed
Front Derailleur
SRAM Force AXS, 12 speed
Shift Levers
SRAM Force AXS, 12 speed
Cassette
SRAM Force, 10-33, 12 Speed
Crank
SRAM Force AXS, 48/35T, DUB, with power meter
Bottom Bracket
SRAM DUB Ceramic, BBright
Chain
SRAM Force, 12 speed
Wheels
Rims
Rear:Reserve 63, 24.4mm IW, Zipp ZR1 ST,12x142mm, XDR freehub, 24h, centerlock, tubeless compatible Front: Reserve 52, 25.4 IW, Zipp ZR1 ST, 24H, centerlock, tubeless compatible
Tires
Vittoria Corsa TLR G 700x28c
Brakes
Brakes
SRAM Force
Cockpit
Stem
Cervélo ST35 Carbon
Handlebar
Cervélo HB14 Carbon
Headset
FSA IS2 1-1/8 x 1-3/8
Seat
Saddle
Selle Italia NOVUS BOOST EVO SuperFlow Ti
Seatpost
Cervélo SP20 Carbon
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 51cm | 54cm | 56cm | 58cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.36 mm | 1.39 mm | 1.42 mm | 1.45 mm | 1.47 mm |
| Bottom Bracket Height | 263 mm | 263 mm | 266 mm | 266 mm | 268 mm |
| Front Center | 579 mm | 580 mm | 581 mm | 588 mm | 604 mm |
| Rake | 58 mm | 52 mm | 46 mm | 43 mm | 43 mm |
| Trail | 56.1 mm | 56.1 mm | 56.2 mm | 56.2 mm | 56.2 mm |
| Stack | 491 mm | 514 mm | 537 mm | 560 mm | 583 mm |
| Reach | 362 mm | 371 mm | 379 mm | 387 mm | 396 mm |
| Top Tube Length | 515 mm | 530 mm | 545 mm | 560 mm | 576 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 480 mm | 510 mm | 540 mm | 560 mm | 580 mm |
| Head Tube Angle | 71 ° | 72 ° | 73 ° | 73.5 ° | 73.5 ° |
| Head Tube Length | 69 mm | 87 mm | 109 mm | 130 mm | 157 mm |
| Chainstay Length | 400 mm | 400 mm | 400 mm | 400 mm | 400 mm |
| Wheelbase | 968 mm | 969 mm | 970 mm | 977 mm | 994 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 70 mm | 70 mm | 67 mm |
| Standover Height | 710 mm | 731 mm | 749 mm | 777 mm | 808 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
About this model
S5 Force eTap AXS belongs to the Cervelo S5 model. 40 bikes variations carry this model name so far. You can easily view all of the Cervelo S5 bikes models from 2023, here.
Model range prices
Cervélo S5 Rival eTap AXS 2023 is the cheapest bike model and costs 6900$. Cervélo S5 Red eTap AXS 2023 is the most expensive one and costs 13000$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Aero bikes average price
Our math shows that the average cost of a dependable Aero bike is 4211$. However, even though the average price of an Aero bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
This bike was released in 2023 and its price was 9000$. Doing a quick comparison, we notice that S5 Force eTap AXS price is 113.73% more expensive than the average cost of an Aero bike.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
The wheels on S5 Force eTap AXS are the 700c carbon type. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The S5 Force eTap AXS has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
