Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 100mm -
Fork RockShox SID SL Select
-
Groupset GX Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon fiber
Suspension Fork
Rockshox SID SL Select, DebonAir spring, Charger RL damper, tapered steerer, 15x110mm, Maxle Stealth, 44mm offset, 100mm travel
Drivetrain
Rear Derailleur
SRAM GX Eagle, 12 speed
Shift Levers
SRAM GX Eagle, 12 speed
Cassette
SRAM GX Eagle, 10-52, 12 Speed
Crank
SRAM GX Eagle, 32T, Boost 148 DUB
Bottom Bracket
SRAM DUB, BSA 73mm
Chain
SRAM GX Eagle, 12 speed
Wheels
Rims
Rear: Race Face ARC Offset 27, 27mm IW, DT Swiss 370, 12x148mm, XD freehub, 28H, 6 bolt, tubeless compatible Front: Race Face ARC Offset 27, 27mm IW, DT Swiss 370, 15x110mm, 24H, 6 bolt, tubeless compatible
Tires
Maxxis Rekon Race, EXO 120TPI, 29x2.4
Brakes
Brakes
SRAM Level TL
Brake Levers
SRAM Level TL
Cockpit
Stem
Race Face Aeffect Alloy, 35mm clamp, 6 degree
Handlebar
Race Face Turbine Alloy, 35mm clamp, 760mm width, 10mm rise
Headset
FSA IS2 1-1/2 x 1-1/2
Seat
Saddle
Cervélo Saddle
Seatpost
Race Face Ride XC Alloy 30.9
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.482 mm | 1.413 mm | 1.363 mm | 1.314 mm |
| Bottom Bracket Height | 312 mm | 312 mm | 312 mm | 312 mm |
| Front Center | 667 mm | 693 mm | 722 mm | 754 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 95 mm | 95 mm | 95 mm | 95 mm |
| Stack | 606 mm | 612 mm | 623 mm | 636 mm |
| Reach | 409 mm | 433 mm | 457 mm | 484 mm |
| Top Tube Length | 582 mm | 608 mm | 635 mm | 666 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 89 mm | 95 mm | 107 mm | 121 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1090 mm | 1116 mm | 1145 mm | 1177 mm |
| Bottom Bracket Drop | 62 mm | 62 mm | 62 mm | 62 mm |
| Standover Height | 705 mm | 740 mm | 782 mm | 810 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
ZHT-5 GX Eagle is a Cervelo Zht 5 model. 5 bikes variations carry this model name so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
Cervélo ZHT-5 GX Eagle 2023 is the cheapest bike model and costs 4000$. Cervélo ZHT-5 XX SL AXS 2023 is the most expensive one and costs 9500$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Crosscountry bikes
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 4000$. Doing a quick comparison, we notice that ZHT-5 GX Eagle price is 109.97% more expensive than the average cost of a Crosscountry bike.
ZHT-5 GX Eagle components
Fork
Cervélo ZHT-5 GX Eagle 2023 bike is equipped with the RockShox SID SL Select fork, and has 100mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
When leaving the production line, the ZHT-5 GX Eagle model has 29″ aluminum wheels. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
When you want to stop the bike in time, the brakes are vital. The ZHT-5 GX Eagle has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
