Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Steel -
Wheels 24" -
Groupset GX Eagle, NX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
S1
128cm - 140cm
S2
138cm - 150cm
S3
148cm - 160cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Rear Shock
Rock Shox Deluxe Select, 165 x 45mm
Drivetrain
Rear Derailleur
SRAM GX Eagle
Shift Levers
SRAM NX Eagle
Cassette
SRAM NX Eagle 10-50t
Crank
SRAM X1 Eagle DUB, 155mm, 30t
Bottom Bracket
73mm Threaded
Chain
SRAM NX Eagle
Wheels
Front Hub
Chromag R4
Rear Hub
Chromag R4
Rims
Chromag Ally
Tires
Maxxis Minion DHF/DHR II
Brakes
Brakes
SRAM Code RSC
Cockpit
Stem
Chromag HiFi BSX 31mm
Handlebar
Chromag Vanguard, 720mm, 31.8mm
Grips
Chromag Format
Headset
44-56 Semi Integrated
Seat
Saddle
Chromag Overture
Seatpost
Chromag Bassix
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | S1 | S2 | S3 |
|---|---|---|---|
| Stack Reach Ratio | 1.51 mm | 1.42 mm | 1.35 mm |
| Bottom Bracket Height | 309 mm | 333 mm | 344 mm |
| Front Center | 667 mm | 720 mm | 740 mm |
| Rake | 40 mm | 44 mm | 44 mm |
| Stack | 553 mm | 578 mm | 578 mm |
| Reach | 367 mm | 407 mm | 427 mm |
| Top Tube Length | 493 mm | 539 mm | 559 mm |
| Seat Tube Angle | 77 ° | 77 ° | 77 ° |
| Seat Tube Length | 305 mm | 330 mm | 355 mm |
| Head Tube Angle | 64 ° | 64 ° | 64 ° |
| Head Tube Length | 95 mm | 95 mm | 95 mm |
| Chainstay Length | 417 mm | 427 mm | 437 mm |
| Wheelbase | 1084 mm | 1147 mm | 1177 mm |
| Bottom Bracket Drop | 8 mm | 15 mm | 15 mm |
| Standover Height | 613 mm | 662 mm | 697 mm |
| Wheels | 24" | 26" | 27" |
| Rider Min Height | 128 cm | 138 cm | 148 cm |
| Rider Max Height | 140 cm | 150 cm | 160 cm |
Model Overview
Minor Threat V2 Minor Threat is a Chromag Minor model. Chromag released 6 bikes variations of this model so far. Take a sneak peek at all Chromag Minor bikes models from 2023, by clicking here.
Model range prices
Chromag Minor Threat S1 2023 is the most affordable bike of this model and has a price of 3400$. On the other hand, Chromag Minor Threat S2 2023, is the most expensive and costs 3400$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Crosscountry bikes average price
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Overview of components
Wheels
The wheels on Minor Threat V2 Minor Threat are the 24″ aluminum type. The 24″ wheels are a good fit for folding bikes, BMX, or children bikes. In conclusion, you can use them better on-road, and less on technical terrain.
Brakes
For your safety, it is important to have quality breaks on your bike. Chromag Minor Threat V2 Minor Threat has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 128 cm – 160 cm (4.2 ft – 5.25 ft). In conclusion, it won’t take much to find one that’s right for you.
