Commençal SUPREME DH V5 SIGNATURE 3 2023
2023 Mountain
Estimate price |
5,541$
Weight | 18.3 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 203mm -
Travel Rear 220mm -
Fork Fox Factory Float 40
-
Groupset GX, Truvativ Descendant -
Suspension Full -
Drivetrain 1 × 7 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Supreme DH V5 29/27, 220 mm travel on S / M / L / XL, 29'', Alloy 6066, triple butted tubes, T4, T6
Suspension Fork
FOX 40 Factory, 203 mm travel, 29", Fit Grip2 damper, HSC, LSC, HSR, LSR, Float Evol. Boost (20 x 110 mm), 52 mm offset, 2 Tokens. More information here
Rear Shock
FOX FLOAT X2 Factory, 250 x 75 mm, HSC, LSC, HSR, LSR, rebound. More information here
Drivetrain
Rear Derailleur
SRAM GX DH, 7 sp
Shift Levers
SRAM GX DH, 7 sp
Cassette
E13 Grappler Race Alloy, 7 sp, 9-24t
Crank
TRUVATIV Descendant DH, 165 mm crank arms, DUB, Chainring: TRUVATIV Descendant DH X-Sync, 34t
Bottom Bracket
SRAM DUB, Pressfit
Chain
KMC X11EL, Black
Chain Guide
E13 LG1 + Bottom Guide, 32-34t
Wheels
Front Hub
Rear: E13 GRAPPLER Race Alloy - Front: E13 GRAPPLER Race Alloy, Rear: 32h, sealed bearings, 12x157mm, black - Front: 32h, sealed bearings, 20x110mm Boost, black
Rear Hub
Rear: E13 GRAPPLER Race Alloy - Front: E13 GRAPPLER Race Alloy, Rear: 32h, sealed bearings, 12x157mm, black - Front: 32h, sealed bearings, 20x110mm Boost, black
Rims
E13 GRAPPLER Race Alloy, REAR: 27.5'', 32h, 30mm inner width on S / M / L / XL - FRONT: 29'', 32h, 30mm inner width on S / M / L / XL
Tires
Rear: SCHWALBE TACKY CHAN - Front: SCHWALBE TACKY CHAN, REAR: 27.5''x2.4'', Super DH, Addix Ultra Soft on S / M / L / XL, Tubeless Easy - FRONT: 29"x2.4", Super DH, Addix Ultra Soft on S / M / L / XL, Tubeless Easy
Brakes
Brakes
TRP DH-R Evo, 4 pistons, resin pads, Rotor: TRP R1 223 mm, 6-bolt, 2.3 mm width
Cockpit
Stem
RIDE ALPHA DH 40, 40 mm extension, direct mount, 31.8 mm
Handlebar
RIDE ALPHA R27, 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on S / M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL
Grips
ODI Longneck, Soft pro compound, single clamp, black
Headset
ACROS ZS56 / ZS56, Alloy cups, sealed bearings
Seat
Saddle
FIZIK Gravita Alpaca X5, MG rails, flexible "wings"
Seatpost
RIDE ALPHA Super Light, 31.6 mm, 250 mm, Alloy 7075
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM High | SM Low | MD High | MD Low | LG High | LG Low | XL High | XL Low |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.48 mm | 1.5 mm | 1.4 mm | 1.42 mm | 1.32 mm | 1.34 mm | 1.27 mm | 1.29 mm |
| Bottom Bracket Height | 352 mm | 353 mm | 352 mm | 353 mm | 352 mm | 353 mm | 352 mm | 353 mm |
| Front Center | 804 mm | 804 mm | 829 mm | 829 mm | 857 mm | 857 mm | 877 mm | 877 mm |
| Rake | 52 mm | 52 mm | 52 mm | 52 mm | 52 mm | 52 mm | 52 mm | 52 mm |
| Trail | 124 mm | 131 mm | 124 mm | 131 mm | 124 mm | 131 mm | 124 mm | 131 mm |
| Stack | 650 | 653 mm | 650 | 653 mm | 650 | 653 mm | 650 | 653 mm |
| Reach | 439 mm | 435 mm | 464 mm | 460 mm | 492 mm | 488 mm | 512 mm | 508 mm |
| Top Tube Length | 598 mm | 600 mm | 623 mm | 625 mm | 651 mm | 653 mm | 671 mm | 673 mm |
| Seat Tube Angle | 67.5 ° | 67.1 ° | 67.5 ° | 67.1 ° | 67.5 ° | 67.1 ° | 67.5 ° | 67.1 ° |
| Seat Tube Length | 370 mm | 370 mm | 370 mm | 370 mm | 370 mm | 370 mm | 370 mm | 370 mm |
| Head Tube Angle | 63.7 ° | 63.3 ° | 63.7 ° | 63.3 ° | 63.7 ° | 63.3 ° | 63.7 ° | 63.3 ° |
| Head Tube Length | 112 mm | 112 mm | 112 mm | 112 mm | 112 mm | 112 mm | 112 mm | 112 mm |
| Chainstay Length | 444 mm | 446 mm | 456 mm | 458 mm | 456 mm | 458 mm | 456 mm | 458 mm |
| Wheelbase | 1248 mm | 1250 mm | 1285 mm | 1287 mm | 1313 mm | 1315 mm | 1333 mm | 1335 mm |
| Bottom Bracket Drop | 3 mm | 2 mm | 3 mm | 2 mm | 3 mm | 2 mm | 3 mm | 2 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" | 27" | 27" | 27" |
About this model
SUPREME DH V5 SIGNATURE 3 is a Commencal Supreme model. 120 bikes variations carry this model name so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
Commençal SUPREME DH TEAM 2023 is the most economical model, with a starting price of 3600$. Commençal SUPREME DH V5 SIGNATURE 2023 on the other hand costs 7400$, and is the most expensive model.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Downhill bikes
According to our math, the average price for a trustworthy Downhill bike is 3391$. However, even though the average price of a Downhill bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
This bike was released in 2023 and its price was 5532$. Comparing the average cost of a Downhill bike to this one, you will see that SUPREME DH V5 SIGNATURE 3 price is 63.14% higher.
Average weight for Downhill bikes
Downhill bikes have an average weight of 15.89 kg (35.03 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
With a weight of 18.3 kg (40.34 lbs), Commençal bike is much heavier than average. In short, the average Downhill bike weight is 15.17% lower than this one.
SUPREME DH V5 SIGNATURE 3 components
Fork
Commençal SUPREME DH V5 SIGNATURE 3 2023 bike is equipped with the Fox Factory Float 40 fork, and has 203mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
From the factory, it comes with the FOX FLOAT X2 Factory rear shock model, which has a travel of 220mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
When leaving the production line, the SUPREME DH V5 SIGNATURE 3 model has 27.5″ aluminum wheels. These wheels will provide you with more control over the bike. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Commençal SUPREME DH V5 SIGNATURE 3 has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
