Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 700c -
Travel Front 63mm -
Fork RST
-
Groupset Acera, Shimano -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium
Suspension Fork
RST "Volant ML", 63mm
Drivetrain
Rear Derailleur
SHIMANO "Acera RD-360", 8speed
Shift Levers
SHIMANO "ST-EF505"
Cassette
SHIMANO "HG31", 11-34 Z.
Crank
SHIMANO "FC-TY301", 28/38/48 Z. 170 mm
Wheels
Front Hub
SHIMANO Nabendynamo "DH3D37" QR
Rear Hub
SHIMANO "FH-TX505" QR
Rims
CONWAY Hohlkammer "X11", Disc
Tires
CONTINENTAL "Ride Tour", 47-622, Reflex
Brakes
Brakes
SHIMANO "BR-MT200"
Cockpit
Handlebar
CONWAY Riser, 700 mm
Seat
Saddle
SELLE ROYAL "Shadow"
Seatpost
CONWAY Patent, 31,6 mm, 350 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.58 mm | 1.58 mm | 1.56 mm | 1.56 mm |
| Stack | 622 mm | 622 mm | 636 mm | 655 mm |
| Reach | 393 mm | 393 mm | 407 mm | 421 mm |
| Top Tube Length | 583 mm | 583 mm | 602 mm | 621 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 450 mm | 500 mm | 550 mm | 600 mm |
| Head Tube Length | 71 mm | 71 mm | 71 mm | 71 mm |
| Chainstay Length | 449 mm | 449 mm | 449 mm | 449 mm |
| Wheelbase | 1072 mm | 1072 mm | 1091 mm | 1112 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
TS 4.0 is a Conway Ts model. 37 bikes variations carry this model name so far. You can get a glimpse at all models from 2022, by clicking on this link.
Model range prices
Conway TS 3.0 2022 is the most affordable bike of this model and has a price of 721$. On the other hand, Conway TS 6.0 Trapez 2022, is the most expensive and costs 1220$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Hybrid bikes
According to our calculations, the average cost of a Hybrid bike that is reliable is 562$. However, this doesn’t mean that if you spend less money on a Hybrid bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2022 for 848$. Comparing this to the average Hybrid bike price, we see that the price is 50.89% more expensive.
Overview of components
Fork
The TS 4.0 comes factory-installed with the RST fork. This has a travel range of 63mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
As for the wheels, Conway TS 4.0 2022, has a 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Conway TS 4.0 is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
Conway TS 4.0 bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
