Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 120mm -
Fork RockShox Judy Silver TK
-
Groupset Deore, Shimano -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
152cm - 161cm
SM
159cm - 169cm
MD
166cm - 177cm
LG
174cm - 184cm
XL
181cm - 190cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
MY23 DRT aluminum
Suspension Fork
RockShox Judy Silver TK Solo Air, 120 millimeters
Drivetrain
Rear Derailleur
Shimano Deore Shadow
Shift Levers
Shimano Deore Rapidfire
Cassette
Shimano Deore 12-speed 10-51T
Crank
Shimano MT510
Bottom Bracket
Shimano
Pedals
Not Included
Wheels
Front Hub
Shimano 110 mm, 15 mm thru axle
Rear Hub
Shimano boost 148 mm, 12 mm thru axle
Rims
Co-op double-wall aluminum tubeless-ready
Tires
XS: Maxxis Rekon Dual Compound 60 TPI, 27.5 x 2.4, S: Maxxis Rekon Dual Compound 60 TPI, 27.5 x 2.4, M: Maxxis Rekon Dual Compound 60 TPI, 29 x 2.4, L: Maxxis Rekon Dual Compound 60 TPI, 29 x 2.4, XL: Maxxis Rekon Dual Compound 60 TPI, 29 x 2.4
Brakes
Brakes
Shimano MT200 hydraulic disc Hydraulic Disc Brake
Brake Levers
Shimano MT200 hydraulic disc
Cockpit
Stem
Forged aluminum 4-bolt
Handlebar
Co-op Riser, 18 mm rise, 8 deg. sweep
Headset
1-1/8 in.-1/12 in., tapered
Seat
Saddle
Co-op Steel Rail
Seatpost
TranzX dropper post
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.37 mm | 1.4 mm | 1.35 mm | 1.32 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm | 51 mm |
| Stack | 573 mm | 573 mm | 620 mm | 633 mm | 652 mm |
| Reach | 394 mm | 419 mm | 444 mm | 469 mm | 494 mm |
| Top Tube Length | 528 mm | 553 mm | 588 mm | 617 mm | 646 mm |
| Seat Tube Angle | 77 ° | 77 ° | 77 ° | 77 ° | 77 ° |
| Seat Tube Length | 360 mm | 395 mm | 430 mm | 465 mm | 500 mm |
| Head Tube Angle | 66 ° | 66 ° | 67 ° | 67 ° | 67 ° |
| Chainstay Length | 424 mm | 424 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1106 mm | 1131 mm | 1175 mm | 1206 mm | 1238 mm |
| Standover Height | 699 mm | 702 mm | 732 mm | 729 mm | 726 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 152 cm | 159 cm | 166 cm | 174 cm | 181 cm |
| Rider Max Height | 161 cm | 169 cm | 177 cm | 184 cm | 190 cm |
About this model
DRT 1.3 completes the Coop Drt model. Co-op released 45 bikes variations of this model so far. You can easily view all of the Coop Drt bikes models from 2023, here.
Model range prices
Co-op DRT 1.0 2023 is the most economical model, with a starting price of 599$. Co-op DRT 3.3 2023 on the other hand costs 3399$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Trail bikes
Our math shows that the average cost of a dependable Trail bike is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
This bike was released in 2023 and its price was 1399$. If we compare this with the average Trail bike cost we notice that the price is 97.43% smaller.
DRT 1.3 components
Fork
Co-op DRT 1.3 2023 bike is equipped with the RockShox Judy Silver TK fork, and has 120mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
As for the wheels, Co-op DRT 1.3 2023, has a 27.5″ aluminum model. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The DRT 1.3 comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
DRT 1.3 comes in 5 sizes, that range from 152 cm – 190 cm (4.99 ft – 6.23 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
A dropper post is included with the DRT 1.3. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
