Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork Suntour XCT
-
Groupset Tourney, Shimano -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
MD
160cm - 176cm
LG
174cm - 186cm
XL
184cm - 205cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALU 6061, M (18"), L (20"), XL (22")
Suspension Fork
Suntour XCT30, HLO DS 100mm, 29"
Drivetrain
Rear Derailleur
Shimano RD-TX800
Shift Levers
Shimano STEF5002/8 sp.
Crank
Shimano FC-TY301, 42-34-24T, 170mm
Chain
KMC Z7/114L
Pedals
SP 510
Wheels
Rear Hub
CTM alloy 6 bolt 32H QR black
Rims
CTM ZX-lite, 622x19 BA, 32H
Tires
Freedom Transition 29x2.25"
Brakes
Brakes
Hayes mechanical disc brake
Cockpit
Stem
CTM LCS 80/31.8 mm
Handlebar
CTM HB-RB11W, 680/31.8 mm
Headset
Something semi-integrated
Seat
Saddle
CTM
Seatpost
CTM SP 300x27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Front Center | 668 mm | 684 mm | 699 mm |
| Rake | 38 mm | 38 mm | 38 mm |
| Top Tube Length | 597 mm | 612 mm | 627 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 460 mm | 510 mm | 560 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 447 mm | 447 mm | 447 mm |
| Wheelbase | 1109 mm | 1124 mm | 1140 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 160 cm | 174 cm | 184 cm |
| Rider Max Height | 176 cm | 186 cm | 205 cm |
Model Overview
REIN 2.0 belongs to the Ctm Rein model. CTM launched 6 bikes of this model so far. You can easily view all of the Ctm Rein bikes models from 2022, here.
Model range prices
CTM REIN 1.0 2022 is the most affordable bike of this model and has a price of 434$. On the other hand, CTM REIN 3.0 2022, is the most expensive and costs 636$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Crosscountry bikes
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
This bike was released in 2022 and its price was 530$. In conclusion, this bike price is 259.43% smaller than the price of the average Crosscountry bike.
Overview of components
Fork
The REIN 2.0 comes factory-installed with the Suntour XCT fork. This has a travel range of 100mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
As for the wheels, CTM REIN 2.0 2022, has a 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, these wheels are not ideal for smaller people.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 160 cm – 205 cm (5.25 ft – 6.73 ft). In conclusion, finding one for you shouldn’t be a problem.
