Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 180mm -
Fork Fox Performance Elite Float 36
-
Groupset GX, NX -
Suspension Full -
Motor Shimano 250W 70Nm mid-drive -
Battery Shimano STEPS E8020 Lithium-ion -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
Fox Float 36 Performance Elite Evol 27.5 Boost 110 180mm
Rear Shock
Fox DHX2 Factory Series 205x65 400
Drivetrain
Rear Derailleur
SRAM GX 11s
Shift Levers
SRAM NX 11s
Cassette
SRAM XG1150-11s 10-42T
Crank
Shimano E8050 HollowTech
Chain
Shimano HG601-11s
Chain Guide
E13 Chain Guide for Steps
Wheels
Front Hub
SRAM MTH716 15x110
Rear Hub
SRAM MTH746 B148x12 XD
Rims
V2 Comp Wide db, 36mm inner
Spokes
Stainless 14G w/Nylok
Tires
Maxxis Minion DHF 27.5x2.8" 3C, EXO, Tubeless Ready,
Brakes
Brakes
SRAM Guide RE
Cockpit
Stem
V2 Pro 35mm*45mm
Handlebar
V2 Pro Riserbar 35mm 780mm
Grips
Devinci Performance w/lock-on
Headset
FSA Orbit 1.5 Zero Stack
Seat
Saddle
SDG Fly Mtn
Seatpost
RaceFace Aeffect 125mm 31.6mm 1x Remote
Motor & Battery
Motor
Shimano STEPS E8000 20Mph
Battery
Shimano STEPS E8020 Lithium-ion
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM High | SM Low | MD High | MD Low | LG High | LG Low | XL Low | XL High |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.4 mm | 1.35 mm | 1.38 mm | 1.32 mm | 1.34 mm | 1.29 mm | 1.29 mm |
| Bottom Bracket Height | 359.5 mm | 364 mm | 364 mm | 358.5 mm | 364 mm | 375.5 mm | 352.5 mm | 364 mm |
| Stack | 583 mm | 591 mm | 600 mm | 604 mm | 609 mm | 613 mm | 619 mm | 622 mm |
| Reach | 423 mm | 423 mm | 443 mm | 438 mm | 463 mm | 458 mm | 478 mm | 483 mm |
| Top Tube Length | 572 mm | 575 mm | 598 mm | 600 mm | 621 mm | 623 mm | 645 mm | 646 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 74.5 ° | 75 ° | 74.5 ° | 74.5 ° | 75 ° |
| Seat Tube Length | 410 mm | 410 mm | 420 mm | 420 mm | 455 mm | 455 mm | 495 mm | 495 mm |
| Head Tube Angle | 65.5 ° | 65 ° | 65.5 ° | 65 ° | 65.5 ° | 65 ° | 65 ° | 65.5 ° |
| Head Tube Length | 105 mm | 105 mm | 115 mm | 115 mm | 125 mm | 125 mm | 140 mm | 140 mm |
| Chainstay Length | 442 mm | 441 mm | 441 mm | 443 mm | 441 mm | 443 mm | 444 mm | 441 mm |
| Wheelbase | 1177 mm | 1196 mm | 1220 mm | 1221 mm | 1244 mm | 1245 mm | 1253 mm | 1270 mm |
| Bottom Bracket Drop | -4 mm | -9 mm | -9 mm | -3 mm | -9 mm | -20 mm | 3 mm | -9 mm |
| Standover Height | 708 mm | 726 mm | 737 mm | 731 mm | 763 mm | 757 mm | 778 mm | 792 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" | 27" | 27" | 27" |
Model Overview
AC NX/GX completes the Devinci E Ac model. There are 8 e-bikes that carry this model name. You can easily view all of the Devinci E Ac e-bikes models from 2018, here.
Model range prices
The most economical model, the Devinci AC NX/GX 2018 has a starting price of 5799$. Devinci AC XT 2018 on the other hand is the most expensive at 6899$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Enduro e-bikes
Our math shows that the average cost of a dependable Enduro e-bike is 4785$. However, even though the average price of an Enduro e-bike is lower, you might still be able to get a top-quality e-bike. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
When Devinci released this model in 2018, its price was 5799$. Comparing this to the average Enduro e-bike price, we see that the price is 21.19% higher.
Overview of components
Fork
The AC NX/GX comes factory-installed with the Fox Performance Elite Float 36 fork. This has a travel range of 180mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels size
When leaving the production line, the AC NX/GX model has 27.5″ aluminum wheels. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Dropper post
Every bike should have a dropper post, and this one does. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
