Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 29" -
Travel Front 160mm -
Travel Rear 150mm -
Fork Fox Performance Elite Float 38
-
Groupset XT, Shimano -
Suspension Full -
Motor Shimano 250W 85Nm mid-drive -
Battery Shimano STEPS E8035 | 504Wh | Lithium-ion -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM High
160cm - 171cm
SM Low
160cm - 171cm
MD High
168cm - 180cm
MD Low
168cm - 180cm
LG High
177cm - 189cm
LG Low
177cm - 189cm
XL High
186cm - 198cm
XL Low
186cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum Optimum G04 150mm
Suspension Fork
Fox Float 38 Performance Elite E-Bike Grip2 160 | 51 Offset
Rear Shock
Fox Float DPX2 P.Elite Trunnion | 0.6Vspacer | 185x55
Drivetrain
Rear Derailleur
Shimano XT M8100 | 12s
Shift Levers
Shimano XT M8100 | 12s
Cassette
Shimano M7100 | 12s | 10-51T | Microspline
Crank
Shimano STEPS SM-CRE80 | 36T
Bottom Bracket
STEPS, press-fit
Chain
Shimano M7100 | 12s
Chain Guide
E*thirteen E*Spec PLus | ISCG05
Wheels
Rims
DT Swiss H1700 29er TA 15x110mm | 30mm inner TR
Tires
Maxxis Minion DHF | 29x2.6wt | 3C MaxxTerra Exo+ TR
Brakes
Brakes
Shimano XT M8120/M8100 | 4 Pistons
Disk Rotors
Shimano RT66 | 203mm
Cockpit
Stem
RaceFace Turbine R35 | B:35mm | L:50mm | 0°
Handlebar
RaceFace Turbine R35 | B:35mm | R:20mm | W:800mm
Grips
Devinci Performance | w/lock-on
Headset
FSA Orbit | 1.5 | Zero Stack
Seat
Saddle
SDG BELAIR 3.0
Seatpost
Fox Transfer Performance Elite | 31.6mm
Motor & Battery
Motor
Shimano STEPS EP800 | 250W | 85Nm
Battery
Shimano STEPS E8035 | 504Wh | Lithium-ion
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM High | SM Low | MD High | MD Low | LG High | LG Low | XL High | XL Low |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.44 mm | 1.36 mm | 1.38 mm | 1.31 mm | 1.34 mm | 1.28 mm | 1.3 mm |
| Bottom Bracket Height | 357 mm | 350 mm | 357 mm | 350 mm | 357 mm | 350 mm | 357 mm | 350 mm |
| Stack | 614 mm | 618 mm | 614 mm | 618 mm | 623 mm | 627 mm | 632 mm | 636 mm |
| Reach | 433 mm | 428 mm | 453 mm | 448 mm | 474 mm | 468 mm | 494 mm | 488 mm |
| Top Tube Length | 576 mm | 578 mm | 597 mm | 598 mm | 619 mm | 621 mm | 642 mm | 644 mm |
| Seat Tube Angle | 77 ° | 76.5 ° | 77 ° | 76.5 ° | 77 ° | 76.5 ° | 76.9 ° | 76.4 ° |
| Seat Tube Length | 410 mm | 410 mm | 420 mm | 420 mm | 455 mm | 455 mm | 495 mm | 495 mm |
| Head Tube Angle | 66 ° | 65.5 ° | 66 ° | 65.5 ° | 66 ° | 65.5 ° | 66 ° | 65.5 ° |
| Head Tube Length | 105 mm | 105 mm | 105 mm | 105 mm | 115 mm | 115 mm | 125 mm | 125 mm |
| Chainstay Length | 461 mm | 463 mm | 461 mm | 463 mm | 461 mm | 463 mm | 461 mm | 463 mm |
| Wheelbase | 1216 mm | 1217 mm | 1236 mm | 1237 mm | 1260 mm | 1261 mm | 1284 mm | 1285 mm |
| Bottom Bracket Drop | 17 mm | 24 mm | 17 mm | 24 mm | 17 mm | 24 mm | 17 mm | 24 mm |
| Standover Height | 746 mm | 740 mm | 753 mm | 748 mm | 777 mm | 771 mm | 803 mm | 798 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 160 cm | 160 cm | 168 cm | 168 cm | 177 cm | 177 cm | 186 cm | 186 cm |
| Rider Max Height | 171 cm | 171 cm | 180 cm | 180 cm | 189 cm | 189 cm | 198 cm | 198 cm |
About this model
DC XT 12S belongs to the Devinci E Dc model. Devinci released 10 e-bikes variations of this model so far. Check out the entire range from 2022 of this model, by clicking this link.
Model range prices
Devinci DC Deore 12S 2022 is the most economical model, with a starting price of 6199$. Devinci DC XT 12S 2022 on the other hand costs 7856$, and is the most expensive model.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Enduro e-bikes average price
If you want an acceptable Enduro e-bike you should know that the average price is 4785$. However, this doesn’t mean that if you spend less money on an Enduro e-bike, you couldn’t get a decent one. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
This e-bike was released in 2022 and its price was 7856$. Doing a quick comparison, we notice that DC XT 12S price is 64.18% higher than the average cost of an Enduro e-bike.
DC XT 12S components
Fork
The Fox Performance Elite Float 38 is included from the factory. It has a travel distance of 160mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
As for the rear shock, this e-bike has the Fox Float DPX2 P.Elite Trunnion | 0.6Vspacer | 185×55 model, with a travel of 150mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels
The DC XT 12S 2022 e-bike is equipped with 29″ aluminum wheels when leaving the factory. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, 29″ wheels will make your e-bike react slower to obstacles you may encounter.
Brakes
Nothing is more important on a bike than its ability to brake properly. Devinci DC XT 12S is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
There are 8 sizes available for this model. Rider height can be anywhere between 160 cm – 198 cm (5.25 ft – 6.5 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Devinci DC XT 12S includes a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
