Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Travel Front 130mm -
Travel Rear 100mm -
Fork RockShox Recon Silver RL
-
Groupset NX, Race Face -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Atroz 6061 T-6 Aluminum 27.5 Trail w/ 4" travel, Optimized Single Pivot, Tapered Steerer, Machine Formed Top Tube, Butted / Formed Down Tube, Sealed Cartridge Bearing Pivot, Aggressive Geometry, 142x12mm Rear Axle w/ Replaceable Hanger
Suspension Fork
Rockshox Recon RL, Solo Air, 130mm Travel, 32mm Stanchions, 15mm Thru-Axle, Tapered Steerer Tube, w/ Rebound and Lock Out Adjust
Rear Shock
Rock Shox Monarch R, Air Shock w/ Rebound Adjust, 184x44mm
Drivetrain
Rear Derailleur
SRAM NX X-Horizon, 11 Speed
Shift Levers
SRAM NX 11 Speed X-Actuation Trigger
Cassette
SRAM PG1130, 11 Speed, 11-42T
Crank
Raceface Æffect Cinch w/ Steel 30T "Narrow Wide"
Bottom Bracket
Raceface Outboard Bearing
Chain
KMC X11EL, 11 Speed
Pedals
DB4L Alloy Platform
Wheels
Front Hub
Formula Hub, 32h Alloy, Boost 110x15mm Thru-axle, Sealed Cartridge Bearings, w/ CNC Disc Mount
Rear Hub
Formula Hub, 32h Alloy, Boost 142x12mm Thru-axle, 4 Sealed Cartridge Bearings, Cassette, w/ CNC Disc Mount
Rims
32H, DDM-5, 27.5 Doublewall
Spokes
14g Stainless Steel
Tires
VEE Rubber, Flow Snap, 27.5x2.35
Brakes
Brakes
Shimano MT200 Hydraulic Disc, w/ 180mm Front and Rear Rotors
Brake Levers
Shimano MT200 Hydraulic
Cockpit
Stem
Race Face Chester, 40mm Reach, 35 Bar Bore
Handlebar
Raceface Chester, 780mm Wide, 35 Bar Bore
Grips
New DB "Flanged" Lock-on, 135mm Silcone
Headset
FSA NO.57, Sealed Cartridge for Tapered Headtube
Seat
Saddle
DB Sync'r Saddle
Seatpost
Alloy Micro Adjust, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.5 mm | 1.37 mm | 1.31 mm |
| Bottom Bracket Height | 345 mm | 345 mm | 345 mm |
| Front Center | 660 mm | 695 mm | 726 mm |
| Rake | 44 mm | 44 mm | 44 mm |
| Trail | 107 mm | 107 mm | 107 mm |
| Stack | 556 mm | 556 mm | 565 mm |
| Reach | 370 mm | 405 mm | 432 mm |
| Top Tube Length | 547 mm | 582 mm | 612 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 380 mm | 430 mm | 480 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 110 mm | 110 mm | 120 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1092 mm | 1127 mm | 1158 mm |
| Bottom Bracket Drop | 10 mm | 10 mm | 10 mm |
| Standover Height | 752 mm | 768 mm | 772 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
Atroz 3 belongs to the Diamondback Atroz model. Diamondback launched 22 bikes of this model so far. Check out the entire range from 2019 of this model, by clicking this link.
Model range prices
Diamondback Atroz 1 2019 is the most affordable bike of this model and has a price of 699$. On the other hand, Diamondback Atroz 3 2019, is the most expensive and costs 1399$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Crosscountry bikes average price
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
At the moment of the release date, Diamondback Atroz 3 price was 1399$. If we compare this with the average Crosscountry bike cost we notice that the price is 36.17% lower.
Atroz 3 components
Fork
The RockShox Recon Silver RL is included from the factory. It has a travel distance of 130mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
As for the rear shock, this bike has the Rock Shox Monarch R model, with a travel of 100mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels
As for the wheels, Diamondback Atroz 3 2019, has a 27.5″ aluminum model. The 27.5″ wheels are a great choice for smaller riders. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Diamondback Atroz 3 has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
Diamondback Atroz 3 bike has 3 sizes, in the range of 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, you won’t have a problem finding one that suits you.
