Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Tourney, Shimano -
Suspension Rigid -
Drivetrain 3 × 7 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Calico 6061-T6 Butted Aluminum Dual Sport Frame w/ Formed Top and Down Tube, Forged Drop Outs, w/ Brake Pivots
Suspension Fork
Dual Sport Fork, Suspension Correct, Hi-Ten Steel, Straight Blade w/ Brake Pivots
Drivetrain
Rear Derailleur
Shimano Tourney TX35, 7 Speed
Front Derailleur
Shimano TZ30, Top Swing, Dual Pull, 31.8mm Band Clamp
Shift Levers
Shimano RS35 Revo, Grip Shift, 3x7 Speed
Cassette
Shimano TZ31, 7 Speed, 14-34T
Crank
Forged Steel Crank w/ Chainguard, 48/38/28T
Bottom Bracket
Sealed Cartridge
Chain
KMC-Z51
Pedals
Alloy Forged
Wheels
Front Hub
32h MX260 Alloy w/ CNC Disc Mount
Rear Hub
32h MX260 Alloy Freewheel w/ CNC Disc mount
Rims
32h Diamondback SL-7 Doublewall
Spokes
14g Stainless
Tires
Dual Sport, 700x40c
Brakes
Brakes
Alloy Linear V-Brake
Brake Levers
Alloy Linear w/ Reach Adjust
Cockpit
Stem
DB 3D Forged, +/- 7° Rise, 31.8mm Bar Bore
Handlebar
DB Laser Series, Low Rise, 660mm Wide, 31.8mm Bar Bore
Grips
Diamondback Dual Density Comfort Grip
Headset
Ahead 1 1/8"
Seat
Saddle
DB Dual Sport Series
Seatpost
DB Laser Series Micro Adjust, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | LG | MD | SM |
|---|---|---|---|---|
| Bottom Bracket Height | 295 mm | 295 mm | 295 mm | 295 mm |
| Rake | 38 mm | 38 mm | 38 mm | 38 mm |
| Top Tube Length | 548 mm | 558 mm | 581 mm | 601 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 356 mm | 406 mm | 457 mm | 508 mm |
| Head Tube Angle | 71 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 140 mm |
| Chainstay Length | 462 mm | 462 mm | 462 mm | 462 mm |
| Wheelbase | 1049 mm | 1048 mm | 1067 mm | 1087 mm |
| Standover Height | 680 mm | 718 mm | 756 mm | 794 mm |
| Wheels | 700 | 700 | 700 | 700 |
Model Overview
Calico ST completes the Diamondback Calico model. There are 4 bikes that carry this model name. You can easily view all of the Diamondback Calico bikes models from 2017, here.
Model range prices
Diamondback Calico 2017 is the cheapest bike model and costs 499$. Diamondback Calico Sport 2017 is the most expensive one and costs 599$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Hybrid bikes
If you want to purchase a solid Hybrid bike, it is important to know that the average cost is 562$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Hybrid bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Calico ST components
Fork material
The fork is made out of steel, so, it can add some extra weight to your bike. However, steel is a pretty tough and durable material.
Wheels size
The Calico ST 2017 bike is equipped with 700c aluminum wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Calico ST comes with Rim brakes. Rim brakes deliver an average performance overall. However, you could spend a little extra and get a bike that has hydraulic brakes.
