Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 700c -
Groupset Acera -
Suspension Rigid -
Drivetrain 1 × 9 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
DB Alternative Road, Disc Brake, Endurance Geometry, Relaxed Head Tube Angle, Fully Butted 6061-T6 Aluminum Formed Top Tube, 1 1/8" Headtube, Replaceable Hanger
Suspension Fork
DB Steel Gravel Disc, 1-1/8" Steerer Tube, w/Fender and Low Rider Mounts
Drivetrain
Rear Derailleur
Shimano Acera RD-T3000, 9 Speed, SGS
Shift Levers
Shimano Acera M3000, 9 Speed
Cassette
Shimano HG201, 9 Speed Cassette, 11-36T
Crank
Aluminum 38T Single Ring w/Aluminum Chainguard
Bottom Bracket
Steel Cartridge
Chain
KMC Z9, 9 Speed
Pedals
DB Platform
Wheels
Front Hub
28h Aluminum Quick Release
Rear Hub
28h Aluminum Quick Release, Cassette
Rims
Diamondback Equation CX, 28h, Doublewall
Spokes
14g Stainless Steel
Tires
Vee Rubber Zilent, Wire Bead, 700x38c
Brakes
Brakes
Tektro Aries Mechanical Disc, w/160mm Front / 140mm Rear Rotor
Brake Levers
Tektro 2 Finger Aluminum
Cockpit
Stem
DB 6061 Aluminum 3D Forged, +/-7° Rise, 31.8mm Bar Bore
Handlebar
DB Flat Bar, 640mm Wide, 31.8mm Bar Bore
Grips
Diamondback Dual Density Grip
Headset
FSA IS-3/ No.11 Integrated Style
Seat
Saddle
Diamondback Performance Gravel Road
Seatpost
DB Aluminum Micro Adjust, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.57 mm | 1.6 mm | 1.61 mm | 1.6 mm |
| Bottom Bracket Height | 276 mm | 278 mm | 280 mm | 280 mm | 280 mm |
| Front Center | 588 mm | 589 mm | 606 mm | 628 mm | 648 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 79 mm | 79 mm | 79 mm | 79 mm | 79 mm |
| Stack | 536 mm | 555 mm | 579 mm | 602 mm | 621 mm |
| Reach | 359 mm | 353 mm | 362 mm | 375 mm | 389 mm |
| Top Tube Length | 520 mm | 520 mm | 535 mm | 555 mm | 575 mm |
| Seat Tube Angle | 73 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 395 mm | 450 mm | 505 mm | 535 mm | 565 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 110 mm | 130 mm | 155 mm | 180 mm | 200 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1013 mm | 1014 mm | 1031 mm | 1053 mm | 1074 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 700 | 733 mm | 777 mm | 806 mm | 831 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Haanjo 1 completes the Diamondback Haanjo model. Diamondback released 60 bikes variations of this model so far. You can easily view all of the Diamondback Haanjo bikes models from 2022, here.
Model range prices
Diamondback Haanjo 1 2022 is the most economical model, with a starting price of 785$. Diamondback Haanjo 8C Carbon 2022 on the other hand costs 4650$, and is the most expensive model.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Gravel bikes
According to our calculations, the average cost of a Gravel bike that is reliable is 2462$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Gravel bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2022 for 785$. In conclusion, this bike price is 213.63% lower than the price of the average Gravel bike.
Haanjo 1 components
Fork material
Haanjo 1 has a steel fork, which tends to be more flexible than carbon forks in general. However, a carbon fork is considerably lighter.
Wheels
When leaving the production line, the Haanjo 1 model has 700c aluminum wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Haanjo 1 comes with Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, it won’t be difficult to find the right one for you.
