Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Claris -
Suspension Rigid -
Drivetrain 2 × 8 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
DB Alternative Road, Disc Brake, Endurance Geometry, Relaxed Head Tube Angle, Fully Butted 6061-T6 Alloy, Formed Top Tube, 1 1/8" Headtube, Replaceable Hanger
Suspension Fork
DB Steel Gravel Disc, 1-1/8" Steerer Tube, w/ Fender Mounts/ Low Rider Mounts
Drivetrain
Rear Derailleur
Shimano Claris RD-2400, 8 Speed
Front Derailleur
Shimano Claris FD-2400, 31.8mm Band Clamp
Shift Levers
Shimano Claris ST-2400 STI, 2x8 Speed
Cassette
Shimano HG50 Cassette, 8 Speed, 11-32T
Crank
Alloy Cross Compact, 46/34T w/ Alloy Big Ring
Bottom Bracket
Steel Cartridge
Chain
KMC Z82, 8 Speed
Pedals
DB4L Alloy Platform
Wheels
Front Hub
28h Alloy Quick Release
Rear Hub
28h Alloy Quick Release, Cassette
Rims
Diamondback Equation, 28h, Doublewall
Spokes
14g Stainless Steel
Tires
Diamondback Interval Wire Bead, 700x38c, Reflective Sidewall, 60TPI
Brakes
Brakes
Tektro Lyra Flat Mount Mechanical Disc, w/ 160mm Front / 140mm Rear Rotors
Brake Levers
Shimano Claris ST-2400
Cockpit
Stem
HED Eroica, 6061 Alloy, 3D Forged, +/-7° Rise, 31.8 Bar Bore
Handlebar
HED Eroica, 7050 Alloy, 8 Degree Flare, 31.8mm Bar Bore
Grips
Diamondback EnduranceTape
Headset
FSA IS-3/ No.11 Integrated Style
Seat
Saddle
DB Eldorado
Seatpost
HED Eroica, 6061 Alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 50cm | 53cm | 56cm | 59cm |
|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.55 mm | 1.6 mm | 1.66 mm |
| Bottom Bracket Height | 279 mm | 279 mm | 279 mm | 279 mm |
| Front Center | 614 mm | 611 mm | 611 mm | 614 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 81 mm | 74 mm | 66 mm | 60 mm |
| Stack | 556 mm | 583 mm | 606 mm | 634 mm |
| Reach | 380 mm | 376 mm | 378 mm | 382 mm |
| Top Tube Length | 532 mm | 547 mm | 567 mm | 587 mm |
| Seat Tube Angle | 74.5 ° | 73 ° | 72.5 ° | 72 ° |
| Seat Tube Length | 475 mm | 505 mm | 535 mm | 565 mm |
| Head Tube Angle | 69 ° | 70 ° | 71 ° | 72 ° |
| Head Tube Length | 130 mm | 155 mm | 175 mm | 200 mm |
| Chainstay Length | 447 mm | 447 mm | 447 mm | 447 mm |
| Wheelbase | 1051 mm | 1048 mm | 1048 mm | 1051 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 760 mm | 781 mm | 813 mm | 840 mm |
| Wheels | 700 | 700 | 700 | 700 |
About this model
Haanjo 2 is part of the Diamondback Haanjo model. Diamondback launched 60 bikes of this model so far. You can get a glimpse at all models from 2019, by clicking on this link.
Model range prices
Diamondback Haanjo 1 2019 is the most affordable bike of this model and has a price of 599$. On the other hand, Diamondback Haanjo 7C Carbon 2019, is the most expensive and costs 2999$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Gravel bikes
If you want an acceptable Gravel bike you should know that the average price is 2462$. However, even though the average price of a Gravel bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, this bike was made available in 2019 for 799$. Comparing this to the average Gravel bike price, we see that the price is 208.14% smaller.
Overview of components
Fork material
Haanjo 2 has a steel fork, which tends to be more flexible than carbon forks in general. However, a carbon fork is considerably lighter.
Wheels size
As for the wheels, Diamondback Haanjo 2 2019, has a 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Diamondback Haanjo 2 has Mechanical Disc brakes installed. They deliver good performance and cost less than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
