Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Claris -
Suspension Rigid -
Drivetrain 2 × 8 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
DB Alternative Road, Disc Brake, Endurance Geometry, Relaxed Head Tube Angle, Fully Butted 6061-T6 Alloy, Formed Top Tube, 1 1/8" Headtube, Replaceable Hanger
Suspension Fork
DB Steel Gravel Disc, 1-1/8" Steerer Tube, w/Fender and Low Rider Mounts
Drivetrain
Rear Derailleur
Shimano Claris RD-2400, 8 Speed, GS
Front Derailleur
Shimano Claris FD-2400, 31.8mm Band Clamp
Shift Levers
Shimano Claris ST-2400 STI, 2x8 Speed
Cassette
Shimano HG50 Cassette, 8 Speed, 11-32T
Crank
Alloy, Compact Cross, 46/34T
Bottom Bracket
Steel Cartridge
Chain
KMC Z8, 8 Speed
Pedals
DB Platform
Wheels
Front Hub
28h Alloy Quick Release
Rear Hub
28h Alloy Quick Release, Cassette
Rims
Diamondback Equation CX, 28h, Doublewall
Spokes
14g Stainless Steel
Tires
Vee Rubber Speedster Wire Bead, 700x40c, 27TPI
Brakes
Brakes
Tektro Mira Post Mount Mechanical Disc, w/160mm Front / 140mm Rear Rotors
Brake Levers
Shimano Claris ST-2400
Cockpit
Stem
DB 6061 Alloy, 3D Forged, +/-7° Rise, 31.8mm Bar Bore
Handlebar
DB Gravel, 6061 Alloy, 8 Degree Flare, 31.8mm Bar Bore
Grips
Diamondback Endurance Gel Tape
Headset
FSA IS-3/ No.11 Integrated Style
Seat
Saddle
Diamondback Performance Mens Gravel Road
Seatpost
DB Alloy, Micro Adjust, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.57 mm | 1.6 mm | 1.61 mm | 1.6 mm |
| Bottom Bracket Height | 280 mm | 280 mm | 280 mm | 280 mm | 280 mm |
| Front Center | 588 mm | 589 mm | 606 mm | 628 mm | 648 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 79 mm | 78 mm | 79 mm | 79 mm | 79 mm |
| Stack | 536 mm | 555 mm | 579 mm | 602 mm | 621 mm |
| Reach | 359 mm | 353 mm | 362 mm | 375 mm | 389 mm |
| Top Tube Length | 520 mm | 520 mm | 535 mm | 555 mm | 575 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 395 mm | 450 mm | 505 mm | 535 mm | 565 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 110 mm | 130 mm | 155 mm | 180 mm | 200 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1013 mm | 1014 mm | 1031 mm | 1053 mm | 1074 mm |
| Bottom Bracket Drop | 70 mm | 72 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 700 | 733 mm | 777 mm | 806 mm | 831 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Haanjo 2 is a Diamondback Haanjo model. There are 60 bikes that carry this model name. You can get a glimpse at all models from 2020, by clicking on this link.
Model range prices
The most economical model, the Diamondback Haanjo 1 2020 has a starting price of 785$. Diamondback Haanjo 8C Carbon 2020 on the other hand is the most expensive at 4600$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Gravel bikes average price
If you want to purchase a solid Gravel bike, it is important to know that the average cost is 2462$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Gravel bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2020 for 925$. If we compare this with the average Gravel bike cost we notice that the price is 166.16% smaller.
Overview of components
Fork material
The fork on this bike is made out of steel, which is tougher than carbon in the case of an impact. However, it can add some extra weight to the bike.
Wheels size
The Haanjo 2 2020 bike is equipped with 700c aluminum wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Diamondback Haanjo 2 has Mechanical Disc brakes installed. They deliver good performance and cost less than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
Sizes
Haanjo 2 comes in 5 sizes, that range from 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, you can easily find one that suits you.
