Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset GRX 800, GRX 600 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
DB Alternative Road, Endurance Geometry, Relaxed Head Tube Angle, Fully Butted 6061-T6 Aluminum Formed Top Tube, Tapered Headtube, Flat Mount Disc, 142x12mm Thru-axle w/Replaceable Hanger
Suspension Fork
DB Gravel Performance, Full Monocoque Carbon, Carbon 12mm Thru Axle Drop Outs, Flat Mount Disc ready, w/Tapered Steerer Tube
Drivetrain
Rear Derailleur
Shimano GRX810, Shadow Plus, 11 Speed
Front Derailleur
Shimano GRX810, 31.8mm Band Clamp
Shift Levers
Shimano GRX600, Dual Control 2x11 Speed
Cassette
Shimano HG70011 Cassette, 11 Speed, 11-34T
Crank
Shimano GRX600, 46/30T
Bottom Bracket
Shimano Outboard Bearing
Chain
KMC X11EL, 11 Speed
Pedals
DB Resin Gravel Platform
Wheels
Front Hub
28h Aluminum Sealed Cartridge, Center Lock, 12mm Thru-axle
Rear Hub
28h Aluminum Sealed Cartridge, Center Lock, 142x12mm Thru-axle, Cassette
Rims
HED Tomcat Disc, 28h, 21mm Internal Width, Tubeless Ready
Spokes
2.0/1.8/2.0 Butted Stainless Steel
Tires
WTB Riddler, Dual DNA Compound, 700x37c
Brakes
Brakes
Shimano BR-RX400 Flat Mount Hydraulic Disc, w/160mm Front / 160mm Rear, RT70 Rotors
Brake Levers
Shimano GRX600
Cockpit
Stem
HED Eroica, 6061 Aluminum 3D Forged, +/-7° Rise, 31.8 Bar Bore
Handlebar
HED Eroica, 7050 Aluminum 12 Degree Flare, 31.8mm Bar Bore
Grips
Diamondback Endurance Gel Tape
Headset
FSA No.42, Sealed Cartridge
Seat
Saddle
WTB Silverado Race
Seatpost
HED Eroica, 6061 Aluminum 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.47 mm | 1.6 mm | 1.62 mm | 1.62 mm |
| Bottom Bracket Height | 280 mm | 280 mm | 280 mm | 280 mm | 280 mm |
| Front Center | 603 mm | 609 mm | 611 mm | 611 mm | 631 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 78 mm | 74 mm | 41 mm | 61 mm | 61 mm |
| Stack | 531 mm | 545 mm | 578 mm | 605 mm | 628 mm |
| Reach | 375 mm | 372 mm | 362 mm | 374 mm | 387 mm |
| Top Tube Length | 520 mm | 520 mm | 540 mm | 555 mm | 575 mm |
| Seat Tube Angle | 75 ° | 75 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 395 mm | 450 mm | 505 mm | 535 mm | 565 mm |
| Head Tube Angle | 70 ° | 70 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 105 mm | 120 mm | 155 mm | 175 mm | 200 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1028 mm | 1034 mm | 1036 mm | 1036 mm | 1057 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 696 mm | 722 mm | 771 mm | 806 mm | 840 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Haanjo 5 is a Diamondback Haanjo model. Diamondback launched 60 bikes of this model so far. You can easily view all of the Diamondback Haanjo bikes models from 2020, here.
Model range prices
The most economical model, the Diamondback Haanjo 1 2020 has a starting price of 785$. Diamondback Haanjo 8C Carbon 2020 on the other hand is the most expensive at 4600$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Gravel bikes average price
According to our math, the average price for a trustworthy Gravel bike is 2462$. However, even if your budget is less than the average, you might still be able to get a top-quality Gravel bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
When Diamondback released this model in 2020, its price was 2000$. Doing a quick comparison, we notice that Haanjo 5 price is 23.1% smaller than the average cost of a Gravel bike.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
When it comes to wheels, the Haanjo 5 bike is equipped with the 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Haanjo 5 comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
Haanjo 5 comes in 5 sizes, that range from 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, you can easily find one that suits you.
