Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 24" -
Groupset Claris -
Suspension Rigid -
Drivetrain 2 × 8 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061-T6 Aluminum Alloy Jr. Haanjo Frame, Hydroformed Top Tube, Disc Tabs, Rack Ready
Suspension Fork
DB Jr. Alloy Urban Fork, Disc Specific, 1 1/8" Steel Steerer
Drivetrain
Rear Derailleur
Shimano Claris FD-2400, 8 Speed
Front Derailleur
Shimano Claris FD-2400, Top Pull, 31.8 Clamp Diameter
Shift Levers
Shimano Claris ST-2400 STI, 2x8 Speed
Cassette
Shimano HG51 Cassette, 8 Speed, 11-28T
Crank
155mm Alloy Arm, CNC Alloy Outer Ring, 46/34T
Bottom Bracket
Square Taper - 5pc
Chain
KMC HG50, 8 Speed
Pedals
Resin Platform
Wheels
Front Hub
24h Semi-Sealed Alloy w/ CNC Disc Mount
Rear Hub
28h Semi-Sealed Alloy Cassette w/ CNC Disc mount
Rims
DB Jr. Equation R Disc 24", Double Wall
Spokes
14g Stainless Steel
Tires
Kenda K161 Kross Cyclo, 24x1 3/8" (37-540)
Brakes
Brakes
Tektro Mira Mechanical Disc w/ 140mm Rotors
Brake Levers
Shimano Claris, w/ Tektro RX2.0 Flat Bar Levers
Cockpit
Stem
DB 3D Forged, +/- 7° Rise, 60mm Reach, 31.8mm Bar Bore
Handlebar
DB Jr. Alloy Flaro Road Bar, 400mm Wide, 31.8mm Bar Bore
Grips
Cork Tape w/ Gel
Headset
Threadless 1 1/8"
Seat
Saddle
Jr. Equip Saddle
Seatpost
Alloy Micro Adjust 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
Model Overview
Haanjo Trail 24 completes the Diamondback Haanjo model. There are 60 bikes that carry this model name. You can get a glimpse at all models from 2017, by clicking on this link.
Model range prices
Diamondback Haanjo Metro 2017 is the cheapest bike model and costs 549$. Diamondback Haanjo Comp Carbon 2017 is the most expensive one and costs 2199$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Road bikes
Our math shows that the average cost of a dependable Road bike is 365$. However, even though the average price of a Road bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, this bike was made available in 2017 for 649$. Doing a quick comparison, we notice that Haanjo Trail 24 price is 77.81% more expensive than the average cost of a Road bike.
Haanjo Trail 24 components
Fork material
Haanjo Trail 24 has an aluminum fork, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Wheels size
When leaving the production line, the Haanjo Trail 24 model has 24″ aluminum wheels. The 24″ wheels are a good fit for folding bikes, BMX, or children bikes. In conclusion, they are great for flat ground or very easy trails.
Brakes
Nothing is more important on a bike than its ability to brake properly. Diamondback Haanjo Trail 24 is equipped with Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, performance-wise there is room for improvement.
