Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Travel Front 100mm -
Fork Suntour XCE
-
Groupset Tourney, Shimano -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Custom Formed AL-6061 Heat Treated Aluminum with Progressive wheel Sizing (27.5" - XS,S) (29" - M,L,XL)
Suspension Fork
SR Suntour XCE-28 100mm of Travel with Pre-Load Adjuster, IS Disc mounts
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Tourney TY300
Front Derailleur
Shimano Tourney TY500, Dual Pull
Shift Levers
Shimano SL-M315 3x7 Speed, Rapid Fire Shifter
Cassette
Shimano MFTZ500 14-28 Tooth Freewheel
Crank
Shimano Tourney TY301, 42/34/24t
Bottom Bracket
BSA, Sealed Cartridge Bearing
Chain
KMX Z-7
Pedals
Wellgo Plastic Body Platform
Wheels
Front Hub
Formula DC-19 Aluminum 6 bolt Disc, Quick Release
Rear Hub
Formula DC-31, Aluminum 6 bolt Disc, Quick Release
Rims
Aluminum MTB DDM-2 Double Wall, 32 hole
Spokes
Steel J-Bend
Tires
Vee Tire Rail Escape, 27.5x2.25" or 29x2.25"
Brakes
Brakes
Radius BH860 Hydraulic Disc, 160mm Front / 160mm Rear
Brake Levers
Radius BH860 Hydraulic Levers with Micro Adjust
Cockpit
Stem
Aluminum MTB 31.8 Bar Bore Stem
Handlebar
Aluminum 31.8mm Bar, 25mm Rise
Grips
MTB Grip
Headset
1-1/8 Semi Integrated,Cartridge Bearing
Seat
Saddle
MTB Saddle
Seatpost
Aluminum 27.2 Post with 15mm Offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.62 mm | 1.55 mm | 1.55 mm | 1.5 mm | 1.46 mm |
| Bottom Bracket Height | 305 mm | 305 mm | 310 mm | 310 mm | 310 mm |
| Front Center | 630 mm | 655 mm | 660 mm | 686 mm | 712 mm |
| Rake | 42 mm | 42 mm | 46 mm | 46 mm | 46 mm |
| Trail | 99 mm | 99 mm | 85 mm | 85 mm | 86 mm |
| Stack | 582 mm | 591 mm | 611 mm | 625 mm | 639 mm |
| Reach | 360 mm | 382 mm | 395 mm | 416 mm | 437 mm |
| Top Tube Length | 534 mm | 559 mm | 584 mm | 609 mm | 634 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 360 mm | 400 mm | 440 mm | 480 mm | 530 mm |
| Head Tube Angle | 68 ° | 68 ° | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 100 mm | 110 mm | 95 mm | 110 mm | 125 mm |
| Chainstay Length | 419 mm | 419 mm | 438 mm | 438 mm | 438 mm |
| Wheelbase | 1044 mm | 1069 mm | 1091 mm | 1117 mm | 1143 mm |
| Bottom Bracket Drop | 50 mm | 50 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 714 mm | 744 mm | 772 mm | 803 mm | 838 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
Hatch 2 belongs to the Diamondback Hatch model. Diamondback launched 9 bikes of this model so far. You can easily view all of the Diamondback Hatch bikes models from 2023, here.
Model range prices
The most economical model, the Diamondback Hatch 1 2023 has a starting price of 575$. Diamondback Hatch 3 2023 on the other hand is the most expensive at 775$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Crosscountry bikes
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 675$. Comparing the average cost of a Crosscountry bike to this one, you will see that Hatch 2 price is 182.22% lower.
Hatch 2 components
Fork
The Suntour XCE is included from the factory. It has a travel distance of 100mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
When it comes to wheels, the Hatch 2 bike is equipped with the 27.5″ aluminum model. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Diamondback Hatch 2 is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
Diamondback Hatch 2 bike has 5 sizes, in the range of 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, it won’t be difficult to find the right one for you.
