Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame aluminium -
Wheels 27.5" -
Travel Front 100mm -
Fork Suntour XCM
-
Groupset Tourney, Altus -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Custom Formed AL-6061 Heat Treated Aluminum with Progressive wheel Sizing (27.5" - XS,S) (29" - M,L,XL)
Suspension Fork
SR Suntour XCM-DS 100mm of Travel with Pre-Load Adjuster, for IS Post Mount Disc
Drivetrain
Rear Derailleur
Shimano Tourney TX800
Front Derailleur
Shimano Tourney TY500 Dual Pull
Shift Levers
Shimano M310 3x7 Speed Rapid Fire Shifter
Cassette
Shimano GH20 Cassette, 7speed, 12-32 Tooth
Crank
Shimano Tourney TY301,42/34/24t
Bottom Bracket
Sealed Cartridge Bearing
Chain
KMC Z7
Pedals
Wellgo Plastic Body
Wheels
Front Hub
Formula DC-20FQuick Release, 6 Bolt, Disc, Quick Release
Rear Hub
Formula DC-22-7RQuick Release, 6 Bolt, Disc, Quick Release
Rims
Aluminum MTB DDM-2 Double Wall, 32 hole
Spokes
Stainless Steel
Tires
Vee Tire Co. Rubber Rail Escape, 27.5x2.25 or 29x2.25"
Brakes
Brakes
Tektro M275 IS Post Mount, Hydraulic with 160mm Rotors F/R
Brake Levers
Tektro M275 Hydraulic
Cockpit
Stem
Aluminum MTB 31.8 Bar Bore Stem
Handlebar
Aluminum 31.8mm Bar, 25mm Rise
Grips
MTB Grip
Headset
1-1/8" Semi Integrated Cartridge Bearing
Seat
Saddle
MTB Saddle
Seatpost
Aluminum 27.2 Post with 15mm Offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.62 mm | 1.55 mm | 1.55 mm | 1.5 mm | 1.46 mm |
| Bottom Bracket Height | 305 mm | 305 mm | 310 mm | 310 mm | 310 mm |
| Front Center | 630 mm | 655 mm | 660 mm | 687 mm | 713 mm |
| Rake | 42 mm | 42 mm | 46 mm | 46 mm | 46 mm |
| Trail | 99 mm | 99 mm | 85 mm | 84 mm | 85 mm |
| Stack | 582 mm | 591 mm | 611 mm | 625 mm | 639 mm |
| Reach | 360 mm | 382 mm | 395 mm | 416 mm | 437 mm |
| Top Tube Length | 534 mm | 559 mm | 584 mm | 609 mm | 634 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 360 mm | 400 mm | 440 mm | 480 mm | 530 mm |
| Head Tube Angle | 68 ° | 68 ° | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 100 mm | 110 mm | 95 mm | 110 mm | 125 mm |
| Chainstay Length | 419 mm | 419 mm | 438 mm | 438 mm | 438 mm |
| Wheelbase | 1044 mm | 1069 mm | 1091 mm | 1118 mm | 1144 mm |
| Bottom Bracket Drop | 50 mm | 50 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 714 mm | 744 mm | 779 mm | 803 mm | 838 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
Hatch 3 is part of the Diamondback Hatch model. There are 9 bikes that carry this model name. You can get a glimpse at all models from 2022, by clicking on this link.
Model range prices
Diamondback Hatch 1 2022 is the most affordable bike of this model and has a price of 575$. On the other hand, Diamondback Hatch 3 2022, is the most expensive and costs 775$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Crosscountry bikes
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
At the moment of the release date, Diamondback Hatch 3 price was 775$. Comparing the average cost of a Crosscountry bike to this one, you will see that Hatch 3 price is 145.81% smaller.
Overview of components
Fork
The Suntour XCM is included from the factory. It has a travel distance of 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels size
The wheels on Hatch 3 are the 27.5″ aluminum type. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Diamondback Hatch 3 is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, you can easily find one that suits you.
