Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 24" -
Travel Front 80mm -
Fork Suntour XCT
-
Groupset X4 -
Suspension Hardtail -
Drivetrain 1 × 8 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 T-6 Aluminum Jr-24" Frame, Formed Tubing, Disc Specific w/ Replaceable Hanger
Suspension Fork
SR Suntour XCT JR 24", 80mm Travel, 28mm Stanchion, Aluminum Lowers, w/ Preload Adjust
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM X4, 8 Speed
Front Derailleur
Upper Chain Guide, 34.9 Clamp Diameter
Shift Levers
SRAM X4 8 Speed
Cassette
SRAM PG820 Cassette, 8 Speed, 11-32T
Crank
Aluminum Arm, w/ 28T Steel Single Ring, 155mm
Bottom Bracket
Sealed Cartridge
Chain
KMC Z82, 8 Speed
Pedals
DB4L Resin Platform
Wheels
Front Hub
32h Aluminum w/ CNC Disc Mount
Rear Hub
32h Aluminum w/ CNC Disc Mount, Cassette
Rims
32h Diamondback Doublewall
Spokes
14g Stainless Steel
Tires
CST, 24x2.25"
Brakes
Brakes
Tektro Aries Mechanical Disc, w/ 160mm Rotors
Brake Levers
Tektro 2 Finger Aluminum Linear w/ Reach Adjust
Cockpit
Stem
Diamondback "Shortie", 45mm Reach, 31.8 Bar Bore
Handlebar
Diamondback, 720mm Wide, 15mm Rise, 31.8 Bar Bore
Grips
DB "Flanged" 135mm Silcone
Headset
FSA IS-3/NO.11 Integrated Style
Seat
Saddle
DB Sync'r Jr. Saddle
Seatpost
Aluminum Micro Adjust, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 24" |
|---|---|
| Stack Reach Ratio | 1.51 mm |
| Bottom Bracket Height | 295 mm |
| Front Center | 553 mm |
| Rake | 40 mm |
| Stack | 499 mm |
| Reach | 330 mm |
| Top Tube Length | 502 mm |
| Seat Tube Angle | 71 ° |
| Seat Tube Length | 317 mm |
| Head Tube Angle | 69 ° |
| Head Tube Length | 105 mm |
| Chainstay Length | 412 mm |
| Wheelbase | 964 mm |
| Bottom Bracket Drop | 23 mm |
| Standover Height | 637 mm |
| Wheels | 24" |
About this model
Line 24 belongs to the Diamondback Line model. Diamondback released 14 bikes variations of this model so far. Take a sneak peek at all Diamondback Line bikes models from 2023, by clicking here.
Model range prices
Diamondback Line 24 2023 is the most affordable bike of this model and has a price of 800$. On the other hand, Diamondback Line 2023, is the most expensive and costs 900$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Mountain bikes average price
According to our math, the average price for a trustworthy Mountain bike is 616$. However, you could also get a good Mountain bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, this bike was made available in 2023 for 800$. Doing a quick comparison, we notice that Line 24 price is 29.87% more expensive than the average cost of a Mountain bike.
Overview of components
Fork
The Line 24 comes factory-installed with the Suntour XCT fork. This has a travel range of 80mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Fork material
When it comes to the fork, this bike has an aluminum one, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Wheels
When it comes to wheels, the Line 24 bike is equipped with the 24″ aluminum model. The 24″ wheels are a good fit for folding bikes, BMX, or children bikes. In conclusion, they are great for flat ground or very easy trails.
Brakes
Nothing is more important on a bike than its ability to brake properly. Diamondback Line 24 is equipped with Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
