Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 80mm -
Fork SunTour XCT
-
Groupset Acera, Tourney -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Overdrive 29" Butted 6061-T6 Aluminum w/ Formed Top / Down Tube, machined headtube, forged drop outs w/replaceable hanger, disc only
Suspension Fork
SR Suntour XCT 80mm travel, 28.6mm stanchions
Drivetrain
Rear Derailleur
Shimano Acera M360 8spd
Front Derailleur
Shimano TX50 dual pull, Low clamp, dual pull, 34.9
Shift Levers
ShimanoAltus EF-51 Easyfire 8spd
Cassette
Shimano HG31 8spd Cassette (11-32t)
Crank
SR Suntour XCT, 42/32/22T
Bottom Bracket
Square Taper - 5pc
Chain
KMC Z82
Pedals
Wellgo Alloy forged, CNC MTB
Wheels
Front Hub
32h SL-7 Alloy w/ CNC Disc Mount
Rear Hub
32h SL-7 Alloy Cassette w/ CNC Disc mount
Rims
DB SL7 29" 32h, Doublewall
Spokes
Black 14g Stainless Steel
Tires
Schwalbe Rapid Rob 29X2.25, KevlarGuard
Brakes
Brakes
Tektro Aires Mechanical Disc Brake, Rotors - 180mm Front/160mm Rear
Brake Levers
Shimano Altus Integrated Brake Lever
Cockpit
Stem
DB 3D Forged,31.8mm, 7°
Handlebar
DB Laser Series 31.8mm, 15mm rise, 670mm
Grips
DB4L 135mm Kraton
Headset
Integrated FSA Drop-in ACB upper, Zero Stack lower internal cup and cartridge bearing, 1 1/8"
Seat
Saddle
DB Race s M-series saddle
Seatpost
DB Micro Adjust 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Rake | 38 mm | 38 mm | 38 mm | 38 mm |
| Top Tube Length | 565 mm | 603 mm | 628 mm | 654 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 406 mm | 457 mm | 508 mm | 559 mm |
| Head Tube Angle | 70 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 95 mm | 105 mm | 120 mm | 135 mm |
| Chainstay Length | 446 mm | 446 mm | 446 mm | 446 mm |
| Wheelbase | 1068 mm | 1097 mm | 1118 mm | 1137 mm |
| Standover Height | 755 mm | 768 mm | 806 mm | 838 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Overdrive is a Diamondback Overdrive model. There are 37 bikes that carry this model name. Take a sneak peek at all Diamondback Overdrive bikes models from 2016, by clicking here.
Model range prices
The most economical model, the Diamondback Overdrive ST 2016 has a starting price of 499$. Diamondback Overdrive 2016 on the other hand is the most expensive at 499$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Crosscountry bikes
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When Diamondback released this model in 2016, its price was 499$. In conclusion, this bike price is 281.76% lower than the price of the average Crosscountry bike.
Overview of components
Fork
The Overdrive comes factory-installed with the SunTour XCT fork. This has a travel range of 80mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
When it comes to wheels, the Overdrive bike is equipped with the 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, these wheels are not ideal for smaller people.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Overdrive comes with Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
